DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-18
Special
M
Function
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
M1125
For COM2(RS-485), communication ready
status reset
○ ○ ○ ○
OFF OFF OFF R/W NO OFF
M1126
For COM2(RS-485), set STX/ETX as user
defined or system defined
○ ○ ○ ○
OFF OFF OFF R/W NO OFF
M1127
For COM2(RS-485), data sending /
receiving / converting completed. (RS
instruction is not supported)
○ ○ ○ ○
OFF OFF OFF R/W NO OFF
M1128
For COM2(RS-485),
Transmitting/Receiving status Indication
○ ○ ○ ○
OFF OFF OFF R/W NO OFF
M1129
For COM2(RS-485), receiving time out
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
M1130
For COM2(RS-485), STX/ETX selection
○ ○ ○ ○
OFF
OFF
-
R/W
NO
OFF
M1131
For COM2(RS-485), ON when
MODRD/RDST/MODRW data is being
converted from ASCII to Hex
○ ○ ○ ○
OFF OFF - R NO OFF
M1132
ON when there are no communication
related instructions in the program
○ ○ ○ ○
OFF - - R NO OFF
M1133
Pulse output ramp-down stop for Y4/CH2
(Y4, Y5)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1134
Pulse output ramp-down stop for Y6/CH3
(Y6, Y7)
EC5
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1136*
For COM3(RS-485/USB), retaining
communication setting
○ ╳ ○ ○
OFF - - R/W NO OFF
M1137
Retain DNET mapping data during non-
executing period
╳ ╳ ○ ○
- - - R/W NO OFF
M1138*
For COM1 (RS-232), retaining
communication setting. Modifying D1036
will be invalid when M1138 is set.
○ ○ ○ ○
OFF - - R/W NO OFF
M1139*
For COM1(RS-232), ASCII/RTU mode
selection (OFF: ASCII; ON: RTU)
○ ○ ○ ○
OFF - - R/W NO OFF
M1140
For COM2 (RS-485), MODRD / MODWR
/ MODRW data receiving error
○ ○ ○ ○
OFF OFF - R NO OFF
M1141
For COM2 (RS-485), MODRD / MODWR
/ MODRW parameter error
○ ○ ○ ○
OFF OFF - R NO OFF
M1142
Data receiving error of VFD-A handy
instructions
○ ○ ○ ○
OFF OFF - R NO OFF
M1143*
For COM2(RS-485), ASCII/RTU mode
selection (OFF: ASCII; ON: RTU)
○ ○ ○ ○
OFF - - R/W NO OFF
M1145*
Read MAC address from the left side
network module (should work with
D1400~1403); available for 12SA2:
V3.00, 12SE: V2.00, 20SX2: V3.00
╳ ╳ ○ ○
OFF OFF OFF R/W NO OFF
M1148
After the instruction DELAY is executed,
the execution of the program following
DELAY is delayed for 5 us.
(ES2/EX2: V3.2; EC5: V1.00)
○
V3.0
V2.6
V1.4
V2.4 OFF OFF - R/W NO OFF
M1156*
Enabling the mask and alignment mark
function on I400/I401(X4) corresponding
to Y0
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1157*
Enabling the mask and alignment mark
function on I500/I501(X5) corresponding
to Y1 (NOT applicable to ES2/EX2:
V3.41; EC5)
ES2/
EX2
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1158*
Enabling the mask and alignment mark
function on I600/I601(X6) corresponding
to Y2
ES2/
EX2
○ ○ ○
OFF OFF - R/W NO OFF
M1159*
Enabling the mask and alignment mark
function on I700/I701(X7) corresponding
to Y3 (NOT applicable to ES2/EX2:
V3.41; EC5)
ES2/
EX2
╳ ╳ ╳
OFF OFF - R/W NO OFF
M1161
8/16 bit mode (ON = 8 bit mode)
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1162
Switching between decimal integer and
binary floating point for SCLP instruction.
ON: binary floating point; OFF: decimal
integer
○
○ ○ ○
OFF - - R/W NO OFF
M1167
16-bit mode for HKY input
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1168
Designating work mode of SMOV
○ ○ ○ ○
OFF
-
-
R/W
NO
OFF
M1177
Enable the communication instruction for
Delta VFD series inverter.
○ ○ ○ ○
OFF - - R/W NO OFF
