DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
9. D1343 (D1353) is the ramp up/down time setting of CH0 (CH1). Available range: 20 ~
32,767ms. Default: 100ms. PLC will take the upper/lower bound value as the set value when
specified value exceeds the available range.
10. D1340 (D1352) is start/end frequency setting of CH0 (CH1). Available range: 6 to 100,000Hz.
PLC will take the upper/lower bound value as the set value when specified value exceeds the
available range.
11. M1305 and M1306 can change the output direction of CH0/CH1 set in D
2
. When S is “-“, D
2
will
be ON, however, if M1305/M1306 is set ON before instruction executes, D
2
will be OFF during
execution of instruction..
12. Ramp-down time of CH0 and CH1 can be particularly modified by using (M1534, D1348) and
(M1535, D1349). When M1534 / M1535 = ON, CH0 / CH1 ramp-down time is specified by
D1348 / D1349.
13. If M1078 / M1104 = ON during instruction execution, Y0 / Y2 will pause immediately and
M1538 / M1540 = ON indicates the pause status. When M1078 / M1104 = OFF, M1538 /
M1540 = OFF, Y0 / Y2 will proceed to finish the remaining pulses.
14. DRVI instruction supports Alignment Mark and Mask function. Please refer to the explanation
in API 59 PLSR instruction.
15. When M1334 or M1335 is enabled, execute API158 DDRVI instruction on CH0 (CH1) to
ramp-down when the conditional contacts are closed. After the conditional contacts are closed,
if you need to use the flags M1334/M1335 to stop the deceleration, you need to enable the
flags M1334/M1335 again. This function is available for the followings:
Series ES2/EX2 ES2-C ES2-E EC5
SX2
SS2 12SE 26SE 28SA2
V3.42 V3.48 V1.00 V1.0 V2.86 V3.28 V2.02 V1.0 V3.0
