Delta DVP-SA2 User Manual

DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
2-40
Special
D
Content
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1110*
Average value of EX2/SX2 analog input
channel 0 (AD 0) When average times in
D1062 is set to 1, D1110 indicates present
value.
EX2
╳ ╳ ○
0 - - R NO 0
D1110
Modbus TCP Server port number can be
modified.
ES2-E
v1.46
╳
SE
v2.04
╳
0 - - R/W NO 502
D1111*
Average value of EX2/SX2 analog input
channel 1 (AD 1) When average times in
D1062 is set to 1, D1111 indicates present
value
EX2
╳ ╳ ○
0 - - R NO 0
D1111
ETHRW instruction is used to set the port
number of the remote connection.
ES2-E
v1.46
╳
SE
v2.04
╳
0 - - R/W NO 502
D1112*
Average value of EX2/SX2 analog input
channel 2 (AD 2) Whenaverage times in
D1062 is set to 1, D1112 indicates present
value
EX2
╳ ╳ ○
0 - - R NO 0
D1113*
Average value of 20EX2/SX2 analog input
channel 3 (AD 3) Whenaverage times in
D1062 is set to 1, D1113 indicates present
value
EX2
╳ ╳ ○
0 - - R NO 0
Displaying the status of the analog input
channel of 30EX2
EX2
╳ ╳ ╳
0 - - R NO 0
D1114*
Enable/disable 20EX2/SX2 AD channels
(0: enable (default) / 1: disable)
bit0~bit3 sets AD0~AD3.
P.S. 30EX2 does not support this function.
EX2
╳ ╳ ○
0 - - R/W YES 0
D1115*
20EX2/SX2 analog input/output mode
setting
EX2
╳ ╳ ○
0 0 0 R/W YES 0
30EX2 analog input/output mode setting
EX2
╳ ╳ ╳
-
-
-
R/W
YES
H’FFFF
D1116*
Output value of analog output channel 0
(DA 0) of EX2/SX2
EX2
╳ ╳ ○
0 0 0 R/W NO 0
D1117*
Output value of analog output channel 1
(DA 0) of 20EX2/SX2
P.S. 30EX2 does not support this function.
EX2
╳ ╳ ○
0 0 0 R/W NO 0
D1118*
EX2/SX2 sampling time of analog/digital
converstion. Default: 2. Unit: 1ms.
Sampling time will be regarded as 2ms if
D1118
≦
2
EX2
╳ ╳ ○
2 - - R/W YES 2
D1120*
COM2 (RS-485) communication protocol
○ ○ ○ ○
H’86
-
-
R/W
NO
H’86
D1121*
COM1(RS-232) and COM2(RS-485) PLC
communication address
○ ○ ○ ○
- - - R/W Yes 1
D1122
COM2(RS-485) Residual number of words
of transmitting data
○ ○ ○ ○
0 0 - R NO 0
D1123
COM2(RS-485) When M1263 is OFF, the
value in D1123 indicates the remaining
bytes of data to be received.
When M1263 is ON, the value in D1123
indicates the bytes of data that are
received.
○ ○ ○ ○
0 0 - R NO 0
D1124
COM2(RS-485) Definition of start
character (STX)
○ ○ ○ ○
H’3A - - R/W NO H’3A
D1125
COM2(RS-485) Definition of first ending
character (ETX1)
○ ○ ○ ○
H’0D - - R/W NO H’0D
D1126
COM2(RS-485) Definition of second
ending character (ETX2)
○ ○ ○ ○
H’0A - - R/W NO H’0A
D1127
Number of pulses for ramp-up operation of
positioning instruction (Low word)
○ ○ ○ ○
0 - - R/W NO 0
D1128
Number of pulses for ramp-up operation of
positioning instruction (High word)
○ ○ ○ ○
D1129
COM2 (RS-485) Communication time-out
setting (ms)
○ ○ ○ ○
0 - - R/W NO 0
D1130
COM2 (RS-485) Error code returning from
Modbus
○ ○ ○ ○
0 - - R NO 0
D1131
Input/output percentage value of
CH0(Y0,Y1) close loop control
○ ○ ○ ○
100 - - R/W NO 100
D1132
Input/output percentage value of
CH1(Y2,Y3) close loop control
○ ○ ○ ○
100 - - R/W NO 100
