Delta DVP-SA2 User Manual

2. Programming Concepts
2-45
Special
D
Content
ES2
EX2
EC5
SS2
SA2
SE
SX2
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1388
ID of the 3
rd
left side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1389
ID of the 4
th
left side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1390
ID of the 5
th
left side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1391
ID of the 6
th
left side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1392
ID of the 7
th
left side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1393
ID of the 8
th
rleft side module
╳ ╳ ○ ○
0
-
-
R
NO
0
D1399*
Starting ID of Slave designated by PLC
LINK
○ ○ ○ ○
- - - R/W YES 1
D1400
Read MAC address from the left side
module (ex: the 1
st
is K100, the 8
th
is
K107) should work with M1145, refer to
M1145 for module availability
╳ ╳ ○ ○
- - - R/W NO 0
D1401~
D1403
Put MAC address in a consecutive order
╳ ╳ ○ ○
- - - R NO 0
D1410
Set the maximum frequency of the ramp
up/down for the fixed slope of Y0 or CH0
(Y0/Y1) in D1410 (Low word). You need to
use M1604 to enable this function.
Available for ES2/EX2: V3.28, ES2-E:
V1.00, EC5: V1.00, 12SA2/SX2: V2.82,
SS2: V3.24, SE: V2.00, 28SA2: V2.90.
○ ○ ○ ○
- - - R/W NO -
D1411
Set the maximum frequency of the ramp
up/down for the fixed slope of Y0 or CH0
(Y0/Y1) in D1411 (High word). You need to
use M1604 to enable this function. Available
for ES2/EX2: V3.28, ES2-E: V1.00, EC5:
V1.00, 12SA2/SX2: V2.82, SS2: V3.24, SE:
V2.00, 28SA2: V2.90.
○ ○ ○ ○
- - - R/W NO -
D1412
Set the maximum frequency of the ramp
up/down for the fixed slope of Y2 or CH1
(Y2/Y3) in D1412 (Low word). You need to
use M1605
to enable this function. Available
for ES2/EX2: V3.28, ES2-E: V1.00, EC5:
V1.00, 12SA2/SX2: V2.82, SS2: V3.24, SE:
V2.00, 28SA2: V2.90.
○ ○ ○ ○
- - - R/W NO -
D1413
Set the maximum frequency of the ramp
up/down for the fixed slope of Y2 or CH1
(Y2/Y3) in D1413 (High word). You need to
use M1605
to enable this function. Available
for ES2/EX2: V3.28, ES2-E: V1.00, EC5:
V1.00, 12SA2/SX2: V2.82, SS2: V3.24, SE:
V2.00, 28SA2: V2.90.
○ ○ ○ ○
- - - R/W NO -
D1415*
Starting address for PLC LINK connection
ID#1 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1416*
Starting address for PLC LINK connection
ID#2 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1417*
Starting address for PLC LINK connection
ID#3 to write
○ ○ ○ ○
- - - R/W YES 10C8
D1418*
Starting address for PLC LINK connection
ID#4 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1419*
Starting address for PLC LINK connection
ID#5 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1420*
Starting address for PLC LINK connection
ID#6 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1421*
Starting address for PLC LINK connection
ID#7 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1422*
Starting address for PLC LINK connection
ID#8 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1423*
Starting address for PLC LINK connection
ID#9 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1424*
Starting address for PLC LINK connection
ID#10 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1425*
Starting address for PLC LINK connection
ID#11 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1426*
Starting address for PLC LINK connection
ID#12 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
D1427*
Starting address for PLC LINK connection
ID#13 to write
○ ○ ○ ○
- - - R/W YES
H’10C8
