D1350*
When M1536 = ON, set the ramp-down
time of CH2 (Y4, Y5) pulse output in
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1351*
When M1537 = ON, set the ramp-down
time of CH3 (Y6, Y7) pulse output in
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1352
Start/end frequency of the 2
nd
group pulse
output CH1 (Y2, Y3)
○ ○ ○ ○
100 - - R/W NO 100
D1353
Ramp up/down time of the 2
nd
group pulse
output CH1 (Y2, Y3)
○ ○ ○ ○
100 - - R/W NO 100
D1354
PLC Link scan cycle (Unit: 1ms)
Max: K32000
D1354 = K0 when PLC Link stops or
when the first scan is completed
○ ○ ○ ○
0 0 0 R NO
0
D1355*
Starting address for PLC LINK connection
ID#1 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1356*
Starting address for PLC LINK connection
ID#2 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1357*
Starting address for PLC LINK connection
ID#3 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1358*
Starting address for PLC LINK connection
ID#4 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1359*
Starting address for PLC LINK connection
ID#5 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1360*
Starting address for PLC LINK connection
ID#6 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1361*
Starting address for PLC LINK connection
ID#7 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1362*
Starting address for PLC LINK connection
ID#8 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1363*
Starting address for PLC LINK connection
ID#9 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1364*
Starting address for PLC LINK connection
ID#10 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1365*
Starting address for PLC LINK connection
ID#11 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1366*
Starting address for PLC LINK connection
ID#12 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1367*
Starting address for PLC LINK connection
ID#13 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1368*
Starting address for PLC LINK connection
ID#14 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1369*
Starting address for PLC LINK connection
ID#15 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1370*
Starting address for PLC LINK connection
ID#16 to read
○ ○ ○ ○
- - - R/W YES
H’1064
D1375 PV of Y4 pulse output (Low word) EC5
╳ ╳ ╳
- - - R/W YES 0
D1376 PV of Y4 pulse output (High word) EC5
╳ ╳ ╳
- - - R/W YES 0
D1377 PV of Y6 pulse output (Low word) EC5
╳ ╳ ╳
- - - R/W YES 0
D1378 PV of Y6 pulse output (High word) EC5
╳ ╳ ╳
- - - R/W YES 0
D1379
Start/end frequency of the 3
rd
group pulse
output CH2 (Y4, Y5)
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1380
Start/end frequency of the 4
th
group pulse
output CH3 (Y6, Y7)
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1381
Ramp up/down time of the 3
rd
group pulse
output CH2 (Y4, Y5)
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1382
Ramp up/down time of the 4
th
group pulse
output CH3 (Y6, Y7)
EC5
╳ ╳ ╳
100 - - R/W NO 100
D1385
Enter the number of connected module for
the PLC to check if the number is matched
with the value in D1143 when power-on.
Available for ES2/EX2/ES2C: V3.62,
ES2/
EX2
╳ ╳ ╳
- - - R/W YES 0
ID of the 1
st
left side module
╳
╳
○
○
ID of the 2
nd
left side module
╳
╳
○
○
