Appendix C Inforamation about TP Series Text Panels
C-7
Special
D
Content
OFF

ON
STOP

RUN
RUN

STOP
Attrib.
Latch
-ed
Default
D1188
Index register E4
0 - - R/W NO 0
D1189
Index register F4
0 - - R/W NO 0
D1190
Index register E5
0 - - R/W NO 0
D1191
Index register F5
0 - - R/W NO 0
D1192
Index register E6
0 - - R/W NO 0
D1193
Index register F6
0 - - R/W NO 0
D1194
Index register E7
0 - - R/W NO 0
D1195
Index register F7
0 - - R/W NO 0
D1240*
When interupt I400/I401/I100/I101 occurs,
D1240 stores the low word of high-speed counter.
0 0 - R NO 0
D1241*
When interupt I400/I401/I100/I101 occurs,
D1241 stores the high Word of the high-speed counter.
0 0 - R NO 0
D1249
Set value for COM1 (RS-232) data receiving time-out (Unit:
1ms, min. 50ms, value smaller than 50ms will be regarded
as 50ms) (only applicable for MODRW/RS instruction) In
RS instruction, no time-out setting if “0” is specified.
0 - - R/W NO 0
D1250
COM1 (RS-232) communication error code (only applicable
for MODRW/RS instruction)
0 - - R/W NO 0
D1252
Set value for COM3 (RS-485) data receiving time-out (Unit:
1ms, min. 50ms, value smaller than 50ms will be regarded
as 50ms) (only applicable for MODRW/RS instruction) In
RS instruction, no time-out setting if “0” is specified
0 - - R/W NO 0
D1253
COM3 (RS-485) communication error code (only applicable
for MODRW/RS instruction)
0 - - R/W NO 0
D1255*
COM3 (RS-485) PLC communication address
- - - R/W YES 1
D1256
↓
D1295
For COM2 RS-485 MODRW instruction. D1256~D1295
store the sent data of MODRW instruction. When MODRW
instruction sends out data, the data will be stored in
D1256~D1295. Users can check the sent data in these
registers.
0 - - R NO 0
D1296
↓
D1311
For COM2 RS-485 MODRW instruction. D1296~D1311
store the converted hex data from D1070 ~ D1085 (ASCII).
PLC automatically converts the received ASCII data in
D1070 ~ D1085 into hex data.
0 - - R NO 0
D1313*
Second of RTC: 00 ~ 59
- - - R/W YES 0
D1314*
Minute of RTC: 00 ~ 59
- - - R/W YES 0
D1315*
Hour of RTC: 00 ~ 23
- - - R/W YES 0
D1316*
Day of RTC: 01 ~ 31
- - - R/W YES 1
D1317*
Month of RTC: 01 ~ 12
- - - R/W YES 1
D1318*
Week of RTC: 1 ~ 7
- - - R/W YES 2/5
D1319*
Year of RTC: 00 ~ 99 (A.D.)
- - - R/W YES 8/10
D1320
Analog I/O module code
- - - R NO #
