Delta DVP series

- 6 -
CR#
Latched
Register
content
Explanation
CH1 CH2 CH3 Ch4 Ch5 Ch6 Ch7 Ch8
#220 X R/W
Temperature
control
_Run/Stop
b0: Ch1
b1: Ch2
b2: Ch3
b3: Ch4
b4: Ch5
b5: Ch6
b6: Ch7
b7: Ch8
0: Stop, 1: Run, Default = K0
#221 X R/W
PID
Auto Tune
b0: Ch1
b1: Ch2
b2: Ch3
b3: Ch4
b4: Ch5
b5: Ch6
b6: Ch7
b7: Ch8
0: Disabled, 1: Auto-tuning
Default = K0
#222 X R/W
Heating/cooli
ng control
b0: Ch1
b1: Ch2
b2: Ch3
b3: Ch4
b4: Ch5
b5: Ch6
b6: Ch7
b7: Ch8
0: Heater, 1: Cooler
Default = K0
#223 X R/W
Preheating
function
b1: Ch2
b2: Ch3
b3: Ch4
b4: Ch5
b5: Ch6
b6: Ch7
b7: Ch8
0: Disable, 1: Enable
Default = K0
※ The CR# listed above do not support RS-485 read/write。
 Temperature / Digital Curve
°C/°F Temperature Measurement Mode:
Max.
Min.
Digital Output
Measured
temperature input
Min.
Max.
[Figure 3]
Thermo-couple
Range of input temperature Range of digital conversion
Min. (°C / °F) Max. (°C / °F) Min. (°C / °F) Max. (°C / °F)
J type -100°C / -148°F 1,150°C / 2,102°F K-1,000 / K-1,480
K11,500 /
K21,020
K type -100°C / -148°F 1,350°C / 2,462°F K-1,000 / K-1,480
K13,500 /
K24,620
R type 0°C / 32°F 1,750°C / 3,182°F K0 / K320
K17,500 /
K31,820
S type 0°C / 32°F 1,750°C / 3,182°F K0 / K320
K17,500 /
K 31,820
T type -150°C / -238°F 390°C / 734°F K-1,500 / K-2,380 K3,900 / K7,340
E type -150°C / -238°F 980°C / 1,796°F K-1,500 / K-2,380 K9,800 / K17,960
N type -150°C / -238°F 1,280 °C / 2,336°F K-1,500 / K-2,380
K12,800 /
K23,360
0 ~ 150mV 0mV 150mV H0 HFFFF
±150mV -150mV 150mV K-30000 K30000
