Delta DVP series User Manual

- 5 -
Error status Value
b15 b14 b13 b12 b11 b10 b9 b8 b7 b6 b5 b4 b3 b2 b1 b0
Abnormal
digital range
of Ch1
K4
(H’4)
00 00 000000 0 1 0 0
Abnormal
digital range
of Ch2
K8
(H’8)
00 00 000000 1 0 0 0
Abnormal
digital range
of Ch3
K16
(H’10)
00 00 000001 0 0 0 0
Abnormal
digital range
of Ch4
K32
(H’20)
00 00
Reserved
0 0 0 0 1 0 0 0 0 0
Abnormal
digital range
of Ch5
K64
(H’40)
00 00 000100 0 0 0 0
Abnormal
digital range
of Ch6
K128
(H’80)
00 00 001000 0 0 0 0
Abnormal
digital range
of Ch7
K256
(H’100)
00 00 010000 0 0 0 0
Abnormal
digital range
of Ch8
K512
(H’200)
00 00 100000 0 0 0 0
Note: Each error status is determined by the corresponding bit (b0 ~ b11) and there may be
more than 2 errors occurring at the same time. 0 = normal; 1 = error.
[Table 1]
 Adjust D/A Conversion Curve
CR#
Latched
Register
content
Explanation
CH1 CH2 CH3 Ch4 Ch5 Ch6 Ch7 Ch8
#100 #115 #130 #145 #160 #175 #190 #205 O R/W
Temperature
SV
Default = K0.
#101 #116 #131 #146 #161 #176 #191 #206 O R/W
Sampling
time (s)
Range: K1 ~ K30 (s).
Default = K2.
#102 #117 #132 #147 #162 #177 #192 #207 O R/W K
P
Default = K121.
#103 #118 #133 #148 #163 #178 #193 #208 O R/W K
I
Integral constant, Default =
K2,098.
#104 #119 #134 #149 #164 #179 #194 #209 O R/W K
D
Derivative constant, Default
= K-29.
#105 #120 #135 #150 #165 #180 #195 #210 O R/W
Default I
value
Range: K-32768 ~ K32767.
Default = K0. Only valid
when PID Stop->Run.
#106 #121 #136 #151 #166 #181 #196 #211 X R
limit of I value
(Low word)
Current accumulated offset
value. Default = K0.
#107 #122 #137 #152 #167 #182 #197 #212 X R
limit of I value
(High word)
#108 #123 #138 #153 #168 #183 #198 #213 O R/W
Preheating
temperature
setting
Range: K-32768 ~ K32767.
Default = K0.
#109 #124 #139 #154 #169 #184 #199 #214 O R/W
Preheating
output setting
Range: K0 ~ K1,000 (unit:
0.1%). Default= K500.
#110 #125 #140 #155 #170 #185 #200 #215 O R/W
Output
percentage
(%)
Range: K0 ~ K1,000 (Unit:
0.1%). Default = K0.
#111 #126 #141 #156 #171 #186 #201 #216 X R
Output width
(ms)
Width of control output,
Default = K0.
#112 #127 #142 #157 #172 #187 #202 #217 X R
Output cycle
(ms)
Cycle of control output,
Default = K0.
