Registers for received data (responding messages)
Register
Data
Descriptions
D1070 low byte
‘0’
30 H
ADR 1
D1070 high byte
‘1’
31 H
ADR 0
D1071 low byte
‘0’
30 H
CMD 1
D1071 high byte
‘3’
33 H
CMD 0
D1072 low byte
‘0’
30 H
Number of data (count by byte)
D1072 high byte
‘C’
43 H
D1073 low byte
‘0’
30 H
Content of address
2101 H
0100 H
PLC automatically converts
ASCII codes and store the
converted value in D1050
D1073 high byte
‘1’
31 H
D1074 low byte
‘0’
30 H
D1074 high byte
‘0’
30 H
D1075 low byte
‘1’
31 H
Content of address
2102 H
1766 H
PLC automatically converts
ASCII codes and store the
converted value in D1051
D1075 high byte
‘7’
37 H
D1076 low byte
‘6’
36 H
D1076 high byte
‘6’
36 H
D1077 low byte
‘0’
30 H
Content of address
2103 H
0000 H
PLC automatically converts
ASCII codes and store the
converted value in D1052
D1077 high byte
‘0’
30 H
D1078 low byte
‘0’
30 H
D1078 high byte
‘0’
30 H
D1079 low byte
‘0’
30 H
Content of address
2104 H
0000 H
PLC automatically converts
ASCII codes and store the
converted value in D1053
D1079 high byte
‘0’
30 H
D1080 low byte
‘0’
30 H
D1080 high byte
‘0’
30 H
D1081 low byte
‘0’
30 H
Content of address
2105 H
0136 H
PLC automatically converts
ASCII codes and store the
converted value in D1054
D1081 high byte
‘1’
31 H
D1082 low byte
‘3’
33 H
D1082 high byte
‘6’
36 H
D1083 low byte
‘0’
30 H
Content of address
2106 H
0000 H
PLC automatically converts
ASCII codes and store the
converted value in D1055
D1083 high byte
‘0’
30 H
D1084 low byte
‘0’
30 H
D1084 high byte
‘0’
30 H
D1085 low byte
‘3’
33 H
LRC CHK 1
D1085 high byte
‘B’
42 H
LRC CHK 0
