DVP-ES2/EX2/EC5/SS2/SA2/SX2/SE&TP Operation Manual - Programming
C-26
Classification API
Mnemonic
PULSE
Function
16 bits
32 bits
14
CML
DCML

Complement
15
BMOV
–

Block move
16
FMOV
DFMOV

Fill move
17
XCH DXCH 
Exchange
18
BCD
DBCD

Convert BIN to BCD
19
BIN
DBIN

Convert BCD to BIN
Four Arithmetic
Operations
20
ADD
DADD

Addition
21
SUB
DSUB

Subtraction
22
MUL DMUL 
Multiplication
23
DIV
DDIV

Division
24
INC
DINC

Increment
25
DEC
DDEC

Decrement
26
WAND
DAND

Logical Word AND
27
WOR DOR 
Logical Word OR
28
WXOR
DXOR

Logical XOR
29
NEG
DNEG

2’s Complement (Negation)
Rotation and
Displacement
30 ROR DROR 
Rotate right
31 ROL DROL 
Rotate left
32 RCR DRCR 
Rotate right with carry
33 RCL DRCL 
Rotate left with carry
34 SFTR – 
Bit shift right
35 SFTL – 
Bit shift left
36 WSFR – 
Word shift right
37 WSFL – 
Word shift left
38
SFWR
–

Shift register write
Rotation and
Displacement
39 SFRD – 
Shift register read
Data Processing
40
ZRST
–

Zone reset
41
DECO
–

Decode
42
ENCO
–

Encode
43
SUM
DSUM

Sum of Active bits
44
BON
DBON

Check specified bit status
45
MEAN
DMEAN

Mean
46
ANS
–
–
Timed Annunciator Set
47
ANR
–

Annunciator Reset
48
SQR
DSQR

Square Root
49
FLT
DFLT

Floating point
High Speed
Processing
53
–
DHSCS
–
High speed counter SET
54
–
DHSCR
–
High speed counter RESET
55
–
DHSZ
–
High speed zone compare
Handy
Instructions
60
IST
–
–
Initial state
61
SER
DSER

Search a data stack
62
ABSD
DABSD
–
Absolute drum sequencer
