- 3 -
Load cell module Voltage output
Series connection to
DVP-PLC MPU
Connectable to the left side of MPU, numbered from 100 to
107 according to the position of module from the closest to
farthest to MPU.
Operation / storage
temperature
Operation: 0 to 55°C (temp.), 50 to 95% (humidity), pollution
degree 2
Storage: -25 to 70°C (temp.), 5 to 95% (humidity)
Vibration / shock immunity
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Complying with DIN1319-1, the tolerance of measured value should be ≤ 0.05% under 20°C
+ 10K temperature range
.
When the corrected ambient temperature and the actual temperature have a difference of
more than 10°C, it is suggested that you re-correct it.
Control Register
CR# Add. Attrib. Register name Explanation
#0 H1000 O R Model name
Set up by the system:
DVP02LC-SL model code = H’4206
#1 H1001 O R Firmware version Display the current firmware version in hex.
#2 H1002 O R/W Characteristic value
Mode 0 (H’0000): 1 mV/V
Mode 1 (H’0001): 2 mV/V, default
Mode 2 (H’0002): 4 mV/V
Mode 3 (H’0003): 6 mV/V
#3 H1003 O R/W
Reaction time for
measurement
Mode 0 (H’0000): 2 ms
Mode 1 (H’0001): 10 ms
Mode 2 (H’0002): 20 ms
Mode 3 (H’0003): 40 ms
Mode 4 (H’0004): 80 ms, default
#4 H1004 O R
Average value of all
channels
Sum up CH1 average value and CH2
average value and equalize them.
Equation: (CH1 average value + CH2
average value)/2
#6 H1006 X R/W
CH1 to CH2 read tare
weight
Read present average value as tare weight
value
bit0: CH1; bit1: CH2; bit2 to bit15: reserved
#7 H1007 O R/W
CH1 to CH2 gross/net
weight
Display present weight as Gross (K0) or Net
(K1). bit0 to bit3: CH1; bit4 to bit7: CH2; bit8
to bit15: reserved.
Take CH1 for example: bit3 to bit0 = 0000,
gross; bit3 to bit0 = 0001, net; bit3 to bit0 =
1111, channel disabled.
#8 H1008 O R/W CH1 tare weight
#9 H1009 O R/W CH2 tare weight
The user can write in the weight or read it by
commands.
Default: K0; Range: -K32,768 to K32,767.
#10 H100A O R/W CH1 average times
#11 H100B O R/W CH2 average times
Default: K10; Range: K1 to K100.
When the set value exceeds the range, it will
automatically be changed to K1 or K100.
#12 H100C X R CH1 average weight
#13 H100D X R CH2 average weight
Display average weight.
#14 H100E X R CH1 present weight
#15 H100F X R CH2 present weight
Display present weight.
#16 H1010 O R/W CH1 standstill times
#17 H1011 O R/W CH2 standstill times
Default: K5
Range: K1 to K500
