CR# Add. Attrib. Register name Explanation
#18 H1012 O R/W CH1 standstill range
#19 H1013 O R/W CH2 standstill range
Default: K10
Range: K1 to K10,000
#20 H1014 O R/W CH1 decimal place
#21 H1015 O R/W CH2 decimal place
Default: K2
Range: K1 to K4
#22 H1016 O R/W
CH1 unit of
measurement
#23 H1017 O R/W
CH1 unit of
measurement
#24 H1018 O R/W
CH2 unit of
measurement
#25 H1019 O R/W
CH2 unit of
measurement
Enter max. 4 ASCII words.
CR#22, CR#24: High word
CR#23, CR#25: Low word
#26 H101A X R/W
Weight correction
command
For the user to correct the weight.
Default: H’0000
H’0001: CH1 Reset to zero command
H’0002: CH1 Weight base point command
H’0003: CH2 Reset to zero command
H’0004: CH2 Weight base point command
#33 H1021 O R/W
CH1 weight base
point
#34 H1022 O R/W
CH2 weight base
point
For CR#33 to CR#34 default = K1,000;
Range: K-32,768 to K32,767
Steps for correction: Take CH1 for example
1: Place no weights on the load cell
2: Set up CR#26 command = “H’0001”
3: Place standard weights on load cell
4: Write the weight of the weights on the plate
into CR#33.
5: Set up CR#26 command = “H’0002”
#35 H1023 O R CH1 max. weight
#36 H1024 O R CH2 max. weight
Set up the max. weight. When the measured
value exceeds the set value, error codes will
be recorded.
#37 H1025 O R/W
Upper limit for CH1
zero point check
#38 H1026 O R/W
Upper limit for CH2
zero point check
Reference for reset to zero. When the weight
is within this range, the status code will be set
to “zero bit”, indicating the current zero
weight status.
Default: K10
Range: K-32,768 to K32,767
#39 H1027 O R/W
Lower limit for CH1
zero point check
#40 H1028 O R/W
Lower limit for CH2
zero point check
Reference for reset to zero. When the weight
is within this range, the status code will be set
to “zero bit”, indicating the current zero
weight status.
Default: K-10
Range: K-32,768 to K32,767
#41 H1029 X R/W
Saving set value
(H’5678)
Save the present set value and write all the
set values into the internal Flash for use next
time DVP02LC-SL is switched on.
H0: No action, Default
H’FFFF: Saving is successful
H’5678: Write to internal Flash
When H’5678 is written in, all set values will
be saved in Flash. When the saving is
completed, CR#41 will become H’FFFF. If the
value written in is not H’5678, it will
automatically return to H0, e.g. write K1 into
CR# to return to K0.
