Delta DVP02LC-SL Instruction Sheet

- 5 -
CR# Add. Attrib. Register name Explanation
#43 H102B X R/W CH1 filter percentage
#44 H102C X R/W CH2 filter percentage
Default: K2
Range: K1 to K5 (Unit: 10%)
#45 H102D X R/W
CH1 filter average
value
#46 H102E X R/W
CH2 filter average
value
Display average weight after filtering.
Condition to enable filter: average time ≥ 30
#50 H1032 X R Status code
b0 (H’0001): CH1 zero weight (empty)
b1 (H’0002): CH2 zero weight (empty)
b2 (H’0004): CH1 exceeds max. weight
(overload)
b3 (H’0008): CH2 exceeds max. weight
(overload)
b4 (H’0010): CH1 stable measured value
b5 (H’0020): CH2 stable measured value
b6 ~ b15: Reserved
#51 H1033 X R Error code
Store all the error statuses. See “Error Code
Table” below. Default: H’0000
#52 H1034 O R/W RS-232 node address
#53 H1035 O R/W
RS-232
communication
setting
#54 H1036 O R/W RS-485 node address
#55 H1037 O R/W
RS-485
communication
setting
For CR#52, CR#54 default = 1
Range: K1 to K255
For CR#53, CR#55 default = H’0000; Range:
ASCII, 9600, 7, E, 1. See “Communication
Format Table” below.
Symbols: O means latched. X means not latched.
R means can read data. W means can write data.
c Error Code Table for CR#51:
bit Content Error bit Content Error
b0 K1 (H’0001)
Power supply
abnormality
b1 K2 (H’0002)
Hardware
abnormality
b2 K4 (H’0004)
CH1 conversion
error
b3 K8 (H’0008)
CH1 SEN voltage
error
b4 K16 (H’0010)
CH2 conversion
error
b5 K32 (H’0020)
CH2 SEN voltage
error
b6 ~ b15 K64 (H’0040) Reserved
Note: Every error status is decided by its corresponding bit, so there might be more than
2 error statuses occurring at the same time. 0 refers to no error; 1 refers to error
occurring.
c Communication Format Table for CR#53, CR#55:
bit15 bit14~bit8 bit7 bit6 bit5 bit4 bit3 bit2 bit1 bit0
ACSII/RTU Reserved Baudrate
Data
length
Stop bit Parity
Description
bit15 ACSII/RTU
0 ASCII 1 RTU
0 9,600 bps 1 19,200 bps
2 38,400 bps 3 57,600 bps
bit7~bit4 Baudrate
4 115,200 bps 5 Else none
bit3 Data length (RTU = 8 bits)
0 7 1 8
bit2 Stop bit
0 1 bit 1 2 bits
0 Even 1 Odd
bit1~bit0 Parity
2 None 3 None
