DVP04/06PT-E2
Operation/storage
Operation: 0°C~55°C (temp.), 5~95% (humidity), Pollution degree2
Storage: -25°C~70°C (temp.), 5~95% (humidity)
Vibration/shock
immunity
International standards: IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Series connection to
DVP-PLC MPU
The modules are numbered from 0 to 7 automatically by their
distance from MPU. No.0 is the closest to MPU and No.7 is the
furthest. Maximum 8 modules are allowed to connect to MPU and
will not occupy any digital I/O points.
Functions Specifications
DVP04/06PT-E2
Celsius (°C) Fahrenheit (°F)
Input
Impedance
Analog input
channel
4/6 channels
Digital data format 2’s complement of 16 bits
Response time 200ms / each channel
Overall accuracy
±0.3% when in full scale (25°C, 77°F)
±0.6% when in full scale within the range of 0 ~ 55°C, 32 ~ 131°F
Applicable sensor
type
04PT：3-Wire Pt100 (DIN 43760-1980 JIS C1604-1989, 100Ω 3850 PPM/°C);
Pt1000 (DIN EN60751, 1 kΩ 3850 PPM/°C); Ni100 / Ni1000(DIN 43760); 0 ~
300Ω/0 ~ 3000Ω input impedance
06PT：3- Wire Pt100 (DIN 43760-1980 JIS C1604-1989, 100Ω 3850 PPM/°C);
Pt1000 (DIN EN60751, 1 kΩ 3850 PPM/°C) ; Ni100 / Ni1000(DIN 43760)；
Cu50；Cu100；JPt100 (JIS C1604-1989)；LG-Ni1000；0 ~ 300Ω/0 ~ 3000Ω input
impedance
Input temperature
range
Pt100: -180°C ~ 800°C
Ni100: -80°C ~ 170°C
Pt1000: -180°C ~ 800°C
Ni1000: -80°C ~ 170°C
JPt100: -180°C ~ 500°C
Cu50: -50°C ~ 150°C
Cu100: -50°C ~ 150°C
LG-Ni1000: -50°C ~ 180°C
Pt100: -180°C ~ 800°C
Ni100: -80°C ~ 170°C
Pt1000: -180°C ~ 800°C
Ni1000: -80°C ~ 170°C
JPt100: -180°C ~ 500°C
Cu50: -50°C ~ 150°C
Cu100: -50°C ~ 150°C
LG-Ni1000: -50°C ~ 180°C
0 ~ 300Ω
0 ~ 3000Ω
Range of digital
conversion
Pt100: K-1,800 ~ K8,000
Ni100: K-800 ~ K1,700
Pt1000: K-1,800 ~ K8,000
Ni1000: K-800 ~ K1,700
JPt100: K-1,800 ~ K5,000
Cu50: K-500 ~ K1,500
Cu100: K-500 ~ K1,500
LG-Ni1000: K-500 ~ K1,800
Pt100: K-1,800 ~ K8,000
Ni100: K-800 ~ K1,700
Pt1000: K-1,800 ~ K8,000
Ni1000: K-800 ~ K1,700
JPt100: K-1,800 ~ K5,000
Cu50: K-500 ~ K1,500
Cu100: K-500 ~ K1,500
LG-Ni1000: K-500 ~ K1,800
K0 ~ K3,000
K0 ~ K30,000
Resolution 0.1°C
0.18°F
*1
0.1Ω
Average function Range: K1 ~ K100.
Self-diagnosis Upper and lower bound detection in all channels
Isolation
Optical coupler isolation between digital circuits and analog circuits. No isolation
among analog channels.
500VDC between digital circuits and Ground
500VDC between analog circuits and Ground
500VDC between analog circuits and digital circuits
500VDC between 24VDC and Ground
*1: The unit of temperature would be displayed as 0.1°C/0.1°F. If the temperature unit is set to be
Fahrenheit, the second decimal place would not be shown.
Control Register
04P 06P
Attrib. Register content Description
#0 #0 O R Model name
DVP04PT-E2 model code = H’0082
DVP06PT-E2 model code = H’00C2
#1 #1 O R Firmware version Display the current firmware version in hex.
