Delta dvp04pt-s User Manual

- 3 -
 Control Register
CR# Address Save Register content Description
#0 H’4064 O R Model name
Set up by the system:
DVP04PT model code = H’8A.
#1 H’4065 O R/W Mode setting
CH1 mode: b0 ~ b3
CH2 mode: b4 ~ b7
CH3 mode: b8 ~ b11
CH4 mode: b12 ~ b15
Take CH1 mode (b3,b2,b1,b0) for
example. The default value is H’0000.
1. (0,0,0,0): PT100
2. (0,0,0,1): NI100
3. (0,0,1,0): PT1000
4. (0,0,1,1): NI1000
5. (1,1,1,1): The channel is disabled.
#2 H’4066 O R/W CH1 average number
#3 H’4067 O R/W CH2 average number
#4 H’4068 O R/W CH3 average number
#5 H’4069 O R/W CH4 average number
Number piece of readings used for the
calculation of “average” temperature on
channels CH1 ~ CH4. Setting range:
For versions prior to V3.04: K1 ~ K4,095.
For versions after V3.05: K1 ~ K20.
Default setting is K10.
#6 H’406A X R CH1 average degrees
#7 H’406B X R CH2 average degrees
#8 H’406C X R CH3 average degrees
#9 H’406D X R CH4 average degrees
Average degrees for channels CH1 ~
CH4.
(Unit: 0.1°C).
#12 H’4070 X R CH1 average degrees
#13 H’4071 X R CH2 average degrees
#14 H’4072 X R CH3 average degrees
#15 H’4073 X R CH4 average degrees
Average degrees for channels CH1 ~
CH4.
(Unit: 0.1°F).
#18 H’4076 X R Present temp. of CH1
#19 H’4077 X R Present temp. of CH2
#20 H’4078 X R Present temp. of CH3
#21 H’4079 X R Present temp. of CH4
Present temperature of channels CH1 ~
CH4.
(Unit: 0.1°C).
#24 H’407C X R Present temp. of CH1
#25 H’407D X R Present temp. of CH2
#26 H’407E X R Present temp. of CH3
#27 H’407F X R Present temp. of CH4
Present temperature of channels CH1 ~
CH4.
(Unit: 0.1°F).
#29 H’4081 X R/W PID mode setting
Set H'5678 to enable PID mode, other set
values are invalid. Default: H’0000.
#30 H’4082 X R Error status
Data register stores the error status.
Refer to the error code chart for details.
#31 H’4083 O R/W
Communication
address setting
RS-485 communication address.
Setting range is 01 ~ 254 and default
setting is K1.
#32 H’4084 O R/W
Communication baud
rate setting
Communication baud rate. For ASCII
mode, date format is 7 bits, even, 1 stop
bit (7, E, 1), while RTU mode, date format
is 8 bits, even, 1 stop bit (8, E, 1).
#32 H’4084 O R/W
Communication baud
rate setting
b0: 4,800 bps (bit/sec).
b1: 9,600 bps (bit/sec). (default setting)
#32 H’4084 O R/W
Communication baud
rate setting
b2: 19,200 bps (bit/sec).
b3: 38,400 bps (bit/sec).
b4: 57600 bps (bit/sec).
b5: 115,200 bps (bit/sec).
b6 ~ b13: Reserved.
b14: switch between low bit and high bit
of CRC code (RTU mode only).
b15: RTU mode.
