Chapter 9 Ethernet Specification and Operation
9-41
9_
Data Type Description
LanguageChar2 USINT
The second ASCII character of the ISO 639-2/T
language
LanguageChar3 USINT
The third ASCII character of the ISO 639-2/T
language
CharStringStruct USINT
The structure of the character string, limited to
the Elementary Data type value 0xD0
(STRING), 0xD5 (STRING2), 0xD9 (STRINGN)
and 0xDA (SHORT_STRING)
CharSet UINT
The character set which the character string is
based on which comes from IANA MIB Printer
Code (RFC 1759).
International String
Defined in
CharStringStruct
An array of 8-bit octet elements which is the
actual international character string
ISO 639-2/T language:
Language First Character Second Character Third Character
English e n G
French f r e
Spanish s p a
Italian i t a
STRUCT
STRUCT of: Composed of any data types.
Ex.: STRUCT of { BOOL, UINT, DINT } = { TRUE, H’1234, H’56789ABC }
1st 2nd 3rd 4th 5th 6th 7th
Byte 01 34 12 BC 9A 78 56
ARRAY
Array of: Composed of one data type.
Ex.: ARRAY of UINTs = { 1，2，3 }
Number 1st 2nd 3rd 4th 5th 6th
Array 01 00 02 00 03 00
EPATH
A path that consists of multiple segments and references the class, instance and attribute of
another object.
Example：Identity Object, Instance attribute 5 = “ 20 01 24 01 30 05 “
