Delta DVP32ES300T User Manual

Chapter 10 CANopen Function and Operation
10-41
10
Index Subindex Object name Data type
Attr
.
Default
value
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01 COB-ID of TxPDO3 Unsigned 32 bits RW 0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
50
H’05
Timer
Unsigned 16 bits
RW
100
H’1803
--
TxPDO4 communication
parameter
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01
COB-ID of TxPDO4
Unsigned 32 bits
RW
0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
50
H’05
Timer
Unsigned 16 bits
RW
100
H’1804
--
TxPDO5 communication
parameter
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01
COB-ID of TxPDO5
Unsigned 32 bits
RW
0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
50
H’05
Timer
Unsigned 16 bits
RW
100
H’1805
--
TxPDO6 communication
parameter
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01
COB-ID of TxPDO6
Unsigned 32 bits
RW
0x80000000
H’02 Transmission mode Unsigned 8 bits RW 0xFF
H’1805
H’03 Inhibit time Unsigned 16 bits RW
50
H’05 Timer Unsigned 16 bits RW 100
H’1806
--
TxPDO7 communication
parameter
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01
COB-ID of TxPDO7
Unsigned 32 bits
RW
0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
50
H’05
Timer
Unsigned 16 bits
RW
100
H’1807
--
TxPDO8 communication
parameter
H’00
Number of valid subindex
Unsigned 8 bits
R
5
H’01 COB-ID of TxPDO8 Unsigned 32 bits RW 0x80000000
H’02
Transmission mode
Unsigned 8 bits
RW
0xFF
H’03
Inhibit time
Unsigned 16 bits
RW
50
H’05
Timer
Unsigned 16 bits
RW
100
H’1A00
--
TxPDO1 mapping parameter
H’00
Number of valid subindex
Unsigned 8 bits
RW
4
H’01
The first mapped object
Unsigned 32 bits
RW
0x20010110
H’02
The second mapped object
Unsigned 32 bits
RW
0x20010210
H’03
The third mapped object
Unsigned 32 bits
RW
0x20010310
