Delta E6-TL-US

62
9.2 Technical data
E6-TL-US
E8-TL-US
BAT T ERY POR T
Compatible battery pack size
5 to 30 kWh
Rated I/O power
5000 W
1)
5000 W
1)
Peak I/O power(30s)
6000 W
7680 W
Acceptable input voltage range
350 V to 480 V
2)
Rated I/O current
15 A
15 A
Peak I/O current (30s)
18 A
18 A
Cycle efficiency charging to discharging (PCS Only)
Peak > 95 %
Fuse rating
30 A
Battery terminal
Screw type
PV INPUT
Absolute maximum input voltage
480 V
2)
Start-up voltage
120 V
Operating MPPT range
50 V to 480 V
Maximum current (per MPPT)
12 A
12 A
MPP tracker
3
3
Maximum allowable MPPT in-paralleled
2 (String)
MPPT scan (Shading option)
15min (high) /~ 30min (default) /~ 60min (low)
MPPT efficiency
>99.6% (Static), >99.3% (Dynamic)
DC disconnect
Integrated
DC terminal
Spring type
AC PORT (ON-GRIG MODE)
Maximum output power
6000 VA
8000 VA
Voltage range
183 Vac to 229 Vac @ 208 Vac
211 Vac to 264 Vac @ 240 Vac
Maximum AC current
24 A
32 A
Frequency range
59.3 Hz to 60.5 Hz
Adjustable frequency range
50 Hz to 66 Hz
Adjustable power factor range
0.85i to 0.85c
THD @ nominal power
< 3 %
Grid support compliance
UL 1741 SA, CA Rule 21, HECO
RGM (optional)
Integrated comply with ANSI C12.20, Class 0.5
Output terminal
Spring type
1) Adjustable value, limited by the output capability of battery pack
2) Adjustable value, Limited by the maximum allowed voltage of battery pack
