Assembling The 3-in-1 Activity Center
1
•Assemblethelegstothebase:Pressthelegbuttonandinsertitintothemountingholeatthebaseasillustrated(Fig.A,B&C).
NOTE:Legswithsquareshapedpinsenterthesquareholesatthebase.Legswithroundshapepinsentertheroundholesatthebase.
•Oncecompleted,makesurealllegsareadjustedtothesameheightlevel.
NOTE:Rearlegsarekeyedtoreartraymounts.
•ConnectthelegswiththewalkertrayasshowninFIGD.
Thensecurethelargeplasticnuts(x4)ontoboltclockwiseasillustratedinFIGF&G.
•Makesureallplasticnutsarefullyhandtighteneddown.
2
•Assemble Walker Tray to Base:
F
G
Photodiagramofstep2
Front
Front
Round pin
close-up
Square pin
close-up
Back
Walker Top
Base
front
Front
