Delta Lil’ - Assembling Wheels to Base; Assembling Seat to Walker Tray

5
Assembling Wheels to Base
Assembling Seat to Walker Tray
3
•AssemblethefrontandrearwheelsasillustratedinFIGG.
•Pushdownonwheelsuntiltheyareinafullyseatedposition.
•InsertthestairstopperintothereceivingholeasillustratedinFIGG.
•Repeatwithfiveotherstoppersandmakesuretheyareproperlyinserted.
4
•Assembletheseatpadtotheplasticringbyinsertingthe(8x)tabsonthe
seatpadintoslotslocatedaroundtheseatringasshowninFIGH.
•TakecompletedseatassemblyandSlide(4x)plasticringtabsthrough
holesandinserttheseattothewalkertrayasillustratedinFIGH(a).
Front
Back
Swivel
Non-Swivel
H(a)
Fabricseat
Plasticring
(G) Seat Ring x1
(H) Seat Pad x1
Indent
Back of Seat
elevated part of seat pad
needs to be aligned with
most elevated area of the
seat ring when assembled
Front of Seat
www.DeltaChildrensProducts.com
Customer Care Tel. 1-(800)-377-3777
Stair Stoppers
