53
16.7 x 23.2 x 5.9 in (425 x 590 x 150 mm)
Natural convection with internal fan
Admissible conductor size AC
Admissible conductor size DC
Bluetooth 4.0 / WiFi / 3G / 4G / Cellular (optional)
Enclosure protection rating
UL 1741, CSA-C22.2 No. 107.1-01
Anti-islanding protection
UL 1699B (Type 1), NEC 2017 Article 690.11
ANSI C12.20 (meets 0.5% accuracy)
UL 1741 SA, California Rule 21, HECO Compliant
1) Un-balance PV input allowed, maximum input power for each MPP tracker is limited with 70% rating power. And total
input is limited with 100% rating power.
2) The maximum AC power value indicates the power an inverter might be able to deliver, but such a maximum AC
power may not necessarily be achieved.
3) Max. output fault current and duration is 140Apk, 2ms duration@208V, 116.8Apk, 6.15ms duration@240V.
Utility interconnection voltage and frequency trip limits and trip times for all models:
Simulated utility source Maximum time (sec) at 60Hz before cessation of
current to the simulated utility
Voltage (V) Frequency (Hz)
< 50% V Rated (60 Hz) 0.16
50% V ≤ V < 88% V Rated (60 Hz) 2
110% V < V <120% V Rated (60 Hz) 1
120% V ≤ V Rated (60 Hz) 0.16
Rated f > 60.5 0.16
Rated f < 59.3 0.16
Trip limit and trip time accuracy for all models:
Voltage: ±1 V (L-L)
Frequency: ±0.01Hz
Time: 1%, but not less than 100ms
