Model Number: MD 11871
46
Installation of the pendular shuttle:
` Hold shuttle centre pin and fit carefully back into the shuttle carrier.
` Refit shuttle-retaining ring and make sure that the following centre pin fixes in the
slot of the shuttle carrier.
` Lock retaining ring by turning levers back into starting position. Refit bobbin case
with bobbin.
Cleaning feed dog
` Remove the needle and sewing foot. Remove the screw on the left hand side of the
needle plate with a screwdriver. Remove the needle plate.
` Clean the teeth of feed dog with a fine brush and refit the needle plate.
` Fit the sewing foot and the needle, the machine is now ready for sewing
Note:
In case of frequent use, it is recommended to clean the feed dog frequently to
obtain the first rate effect of needlework.
