Model Number: MD 11871
47
Oiling the machine
Note:
Apply only one or two drops of machine oil, or cloth will be stained.
If the machine should not run well after being out of use for a long period, apply a
few drops of oil before running it and the machine gets full operating ability.
Oiling the machine behind the front flap
Remove the cover (1), screw (2) and front flap (3).
Oiling is required for the positions marked in the illustration.
Oiling the pendular shuttle
Open the bobbin cover case (4).
Oiling is required for the positions marked in the illustration
