47
External Wiring
T
T
To PERFORMANCE
" Room Thermostat"
Snap Set
Circulator
Zone 1
Thermostat
zone 1
Honeywell
R845A
Relay
120
H
VA C
N
Circulator
Zone 2
Thermostat
zone 2
Additional zones may be
added as shown above
C
1
6
2
1
4
3
5
6
2
1
4
3
5
T
T
TT
Fig. 34: Field wiring with zone circulators.
