Chapter 3 Installation
3.3 Installation_ Model: STS30002SR10135

z
Front installation
TEST
O/P
S1 S1-ON
S2
S2-ON
NETWORK
RESET
LOCAL

z
Rear installation
TEST
O/P
S1 S1-ON
S2 S2-ON
NETWORK
RESET
LOCAL
NOTE :
After installation, the surplus four bracket screws, two rack nuts
and two rack screws are spare parts.
