A.
Model T4738
Iffaucetdoesnotdivertwaterfromthespouttothehandshower,checkthat
theliftrod(1)issecurelythreadedintothediverter(2).Iftheproblempersists
removetheliftrodandspout.ReplacethediverterassemblyRP40668.
B.
Maintenance

Iffaucetleaksfromspoutoutlet–Shutoffwatersupplies–
ReplaceSeatsandSprings(1).
*
Ifleakpersists–Shutoffwatersupplies–
ReplaceStemUnitAssembly(2).
*

*Installstems(2)correctlyforproperhandlerotation:
 •Forlever handles,thestops(3)mustpointtotherightwhen
installed.
A.
1
2
RP40668
DiverterAssembly
EnsambledelDesviador
Dérivation
Mantenimiento

Silallavedeaguatienefiltracionesdelasalidadelsurtidor–
Cierrelossuministrosdeagua–
CambielosAsientosylosResortes(1).*
Silafiltraciónpersiste–Cierrelossuministrosdeagua–
CambieelensambledelaUnidaddelaEspiga(2).*
 
*Instalelasespigas(2)correctamenteparaquelamanija
gireapropiadamente.
 •Paralasmanijasdepalanca,cuandoinstalados,lostopes(3)
debenseñalarhacialaderecha. 
Modelo T4738
Silallavedeaguanodesvíaelaguadelsurtidorhacialaregaderademano,
examinesilabarritadealzar(1)estáfijamenteenroscadaeneldesviador(2).
Sielproblemapersistequitelabarritadealzaryelsurtidor.Reemplaceel
desviadorconRP40668.
B.
A.
Entretien

Silerobinetfuitparlasortiedubec,interrompezl’arrivéed’eau,
puisremplacez-lessiègesetlesressorts(1).*
Silafuitepersiste,interrompezl’arrivéed’eauetremplacezles
obturateurs(2).*

*Installezlesobturateurs(2)correctementpourquelespoignées
tournentdanslebonsens.
•S’ils’agitdemanettes,lesbutées(3)doiventpointerversla
droiteaprèsl’installation.
Modèle T4738
Silerobinetnedérivepasl’eaudubecversladoucheàmain,assurez-vous
quelatirette(1)estbienvisséedansladérivation(2).Sileproblèmepersiste,
retirezlatiretteetlebec.RemplacezladérivationRP40668.
B.
A.
T4738
B.
1
2
3
1
2
3
4
51284   Rev.B
