- 4 -
Model
Item
Output terminal
Relay Transistor
Voltage specifications 250VAC, < 30VDC 12-24VDC
Current
specifications
Resistive 1.5A /1 point (5A/COM) 1A /1 point (5A/COM)
Inductive
#1
-
Bulb 20WDC/100WAC -
Response time
OffOn
Approximately 10 ms Approximately 10 ms
#1: Life curves
Contact
Current(A)
20
0.5
0.1
0.2
30
50
0.3 0.7 1 2
200
300
500
100
1,000
2,000
3,000
O
p
e
r
a
t
i
o
n
(
X
1
0
)
3
120VAC Resistive
30VDC Inductive(t=7ms)
240VAC Inductive(cos 0.4)ψ=
120VAC Inductive(cos =0.4)ψ
30VDC
Inductive
(t=40 ms)
Figure 6
Model
Item
Specifications for the analog input/output of TP04P-22XA1R/T
Voltage input Current input Voltage output Current output
Analog range ±10V ±20m
A
±10V 0~20m
A
Digital conversion range ±2000 ±1000 ±2000 0~4000
Resolution
12 bits
(1LSB=5mV)
11 bits
(1LSB=20uA)
12 bits
(1LSB=5mV)
12 bits
(1LSB=5uA)
Input impedance 1MΩ 250Ω -- --
Output impedance -- -- 100Ω
Overall accuracy
25°C(77°F): The error is

0.5% of the input within the range
0~55°C(32~131°F): The error is 1% of the input within the range
Response time 3ms/Channel
Isolation None
Absolute Input range ±15V ±32m
A
-- --
Digital data format
Two's complement of a 16-bit number
11 bits are significant bits.
Maximum current output
(Load allowed)
--
10m
A
(1KΩ~2MΩ)
0~500Ω
Protection
The voltage output is equipped with a short circuit protection and the
overcurrent protection. (If the voltage output is short-circuited for a
long time, it may be damaged.) The current output can be an open
circuit.
Model
Item
Specifications for the analog input/output of TP04P-21EX1R/T
Current input Current output
Analog I/O range 0~20m
A
0~20m
A
Digital conversion range 0~4000 0~4000
Resolution 12 bits(1LSB=5u
A
) 12 bits(1LSB=5u
A
)
Input impedance 250Ω --
Output impedance -- 100Ω
Response time 3ms/Channel
Absolute Input range 0~32m
A
--
Maximum current output
(Load allowed)
-- 0~500Ω
Specifications for temperature measurement
Sensor type 2-wire/3-wire Pt100
Driving current 1.6mA
Temperature input range -20°C~300°C
Digital conversion range -200~3000
Resolution 0.1°C
Overall accuracy
25°C(77°F): The error is

0.5% of the input within the range
0~55°C(32~131°F): The error is 1% of the input within the range
Response time 300ms×Number of channels
Isolation None
