Delta TP04P - TP04 P Electrical Specifications

- 3 -
Model
Spec.
TP04P series
Extension interface Slot for a program copy card
Panel components Description
Alarm LED indicator
(Red)
Status 1: when turning on the power, this LED will start blinking
slowly and when the power is ON, this LED will be off.
Status 2: when the user-defined conditions are met, LED will blink
every 1 second along with an alarm sound.
Power LED indicator
(Green)
When the power is ON, this LED will be ON.
Display area LCD module; it is used to display current program status.
Numeric keys
Keys 0~9 can be used for inputting constants. Users can also define
the keys by themselves.
Function keys Users can define the keys.
Enter key (ENT)
If the input value is correct, press the key to confirm the setting.
Users can define the key in the user page.
Arrow keys
Up: for increasing the setting value or go to the previous page
Down: for decreasing the setting value or go the next page
Left/Right: for selecting the position of the setting value
Users can redefine functions of the arrow keys in the user page.
 Electrical Specifications
Model
Spec.
TP04P-
16TP1R/T
TP04P-
32TP1R/T
TP04P-
22XA1R/T
TP04P-
21EX1R/T
CPU LPC1787FBD208
Program memory 1 MB-flash memory
RAM of the system 64K Bytes
Power supply voltage
24VDC (-15% ~ 20%) (With counter-connection protection on the
polarity of DC input power)
Power consumption
3W / 2.5W 5W / 4.5W 4.7W / 4.5W 4.7W / 4.5W
Power protection With counter-connection protection on the polarity of DC input power
Insulation resistance > 5 MΩ (all I/O point-to-ground insulation resistance: 500 VDC)
Noise immunity
ESD (IEC 61131-2, IEC 61000-4-2): 8KV Air Discharge
EFT (IEC 61131-2, IEC 61000-4-4): Power Line: 2KV, Digital I/O:
1KV, Analog & Communication I/O: 1KV
Damped-Oscillatory Wave: Power Line: 1KV, Digital I/O: 1KV
RS (IEC 61131-2, IEC 61000-4-3): 26MHz~1GHz, 10V/m
Ground
The diameter of ground cannot be less than the diameter of the
power cable. (If several TP04P are used, they should be grounded
directly.)
Operating temperature
for hardware
0°C~50°C: Relative humidity: 20%-90% RH (non-condensing)
Storage temperature
for hardware
-20°C~60°C
Waterproof class of the
front panel
IP66/NEMA4
Vibration/Shock
resistance
International standards IEC61131-2, IEC 68-2-6 (TEST Fc)/
IEC61131-2 & IEC 68-2-27 (TEST Ea)
Weight 420g 444g
432g 432g
Dimensions 175.8 × 108.6 × 59.2 mm (Width(W) × Height(H) × Deep(D))
Cooling method Natural air cooling
Model
Item
Input terminal
24VDC (-15% ~ 20%) single common terminal
Input number X0, X1 X2~X7, X10~X17
Input type DC (Sinking or sourcing)
Input voltage (±10%) 24VDC, 5mA
Input impedance 4.7k ohm
Maximum frequency 10KHz 60Hz
Action level
OffOn > 16.5 VDC
OnOff < 8 VDC
Response
time
OffOn <20us
10ms
OnOff <50us
