Chapter 4 Parameters  VFD-EL-W
4-11
Parameter Function Setting Default Customer
23:
Simple positioning stop by forward
limit
24:
Simple positioning stop by reverse
limit
25: Multi-
pump control by Hand or Auto
mode
26: Auto-trigger preheating function
27: Fire mode enabled (without
Operation Command)
28:
Fire mode enabled (with Operation
Command)
04.09
Multi-function Input Contact
Selection
0–63 0
04.10
Digital Terminal Input Response
Time
1–20 (*2ms) 1
04.11
Minimum AVI Voltage 0.0–10.0 V
0.0
04.12
Minimum AVI Frequency
(percentage of Pr.01.00)
0.0–100.0% [100% corresponds to
Fmax (Pr.01.00)]
0.0
04.13
Maximum AVI Voltage 0.0–10.0 V
10.0
04.14
Maximum AVI Frequency
(percentage of Pr.01.00)
0.00–100.00% [100% corresponds to
Fmax (Pr.01.00)]
100.00
04.15
Minimum ACI Current 0.0–20.0 mA
4.0
04.16
Minimum ACI Frequency
(percentage of Pr.01.00)
0.00–100.00%
[100% corresponds to
Fmax (Pr.01.00)]
0.0
04.17
Maximum ACI Current 0.0–20.0 mA
20.0
04.18
Maximum ACI Frequency
(percentage of Pr.01.00)
0.00–100.00% [100% corresponds to
Fmax (Pr.01.00)]
100.0
04.19
MI Terminal Control Mode Selection
0: Mode 1
(MI1: Start-up/Stop terminal; MI2 &
MI3: multi-function input terminals)
1: Mode 2
(MI1/MI2/MI3 support two-wire /
three-wire start-up)
0
04.26
Display the Status of Multi-function
Input Terminal
Read only
Read
only
04.27
Internal/External Multi-function
Input Terminals Selection
0–4095
0
04.28
Internal Terminal Status
0–4095 0
04.29
Delay Time of Multi-function Input
Terminal (MI1) Turn On
0.00–360.00 sec. 0.00
04.30
Delay Time of Multi-function Input
Terminal (MI1) Turn Off
0.00–360.00 sec. 0.00
04.31
Delay Time of Multi-function Input
Terminal(MI2) Turn On
0.00–360.00 sec. 0.00
04.32
Delay Time of Multi-function Input
Terminal (MI2) Turn Off
0.00–360.00 sec.
0.00
04.33
Delay Time of Multi-function Input
Terminal (MI3) Turn On
0.00–360.00 sec.
0.00
