4
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
4-1
CHAPTER 4 DIGITAL KEYPAD OPERATION
This chapter describes the various controls and indicators found on the digital keypad/display
PU01. The information in this chapter should be read and understood before performing the
start–up procedures described in the chapter of parameter settings.
ª Description of the Keypad
ª Description of Display
ª Keypad Operation Modes & Programming Steps
VFD-PU01 Dimensions: mm (inch)
6.5 [0.26]
19.0 [0.75]
110.0 [4.33]
73.0 [2.87]
97.0 [3.82]
44.0 [1.73]
77.0 [3.03]
M4* 0.7(2X)
DATA
PROG
STOP
MODE
RUN
JOG
?
4
0
.
0
[
1
.
5
8
]
