Delta VFD110B43A - VFD550 B43 A 55.0 Kw (75 HP) 460 V; 3-Phase; VFD750 B43 A 75.0 Kw (100 HP) 460 V; 3-Phase

C
VFD-B Series
DELTA ELECTRONICS, INC. ALL RIGHTS RESERVED
C-9
VFD550B43A 55.0 kW (75HP) 460V / 3-phase
VFD750B43A 75.0 kW (100HP) 460V / 3-phase
Unit: mm (inches)
660.0 [25.98]
385.0 [15.16]
425.0 [16.73] 264.0 [10.39]
R6.5[0.25]
13.0[0.51]
21.0[0.83]
631.0 [24.84]
130.4 [5.13]
280.0 [11.02]
18.0 [0.71]
