Example 3:
The example also shows the popular method. The whole scale of the potentiometer can be
used as desired. In addition to signals of 0 to 10V and 4 to 20mA, the popular voltage signals
also include signals of 0 to 5V, 20 to 4mA or that under 10V. Regarding the setting, please
refer to the following examples.
Max. Output Freq.
Pr.01-00
Bias
Adjustment
0V 10V
4mA
0Hz
10Hz
60Hz
20mA
-2V
XV
Pr. 04-13 = X 100% 83.3% =
10V
12V
Negative bias:
60-10Hz
10V
10-0Hz
XV
=
XV =
100
50
= 2V
Pr.04-11 = X 100%
2
10
Example 4:
This example shows a potentiometer range of 0 to 5 Volts. In addition to adjust gain, you also
can set Pr. 01-00 to 120Hz.
Factory Settings
Pr.01-00=60Hz--Max. output Freq.
Pr.04-11=0.0% bias adjustment
Pr.04-12=0 -- bias polarity
Pr.04-13=200% -- pot. freq. gain
Pr.04-14=0 -- REV motion disable in negative bias
Max. Output Freq.
60Hz
Pr.01-00
0H
z
0V
5V
Calculation of gain
10V
5V
)X100% = 200%
30Hz
Gain
adjustment
Example 5:
In this example a 1-volt negative bias is used. In a noisy environment, it is advantageous to
use negative bias to provide a noise margin (1V in this example).
Max. Output Freq.
60Hz
Pr.01-00
0Hz
0V
10V
Factory Settings
Pr.01-00=60Hz--Max. output Freq.
Pr.04-11=10.0% -- bias adjustment
Pr.04-12=1 -- bias polarity
Pr.04-13=100% -- pot. freq. gain
Pr.04-14=0 -- Rev. motion disable in negative bias
Negative
bias 6H
z
1V
54Hz
