Delta VFD110C43A-21 - Magnetic Contactor; Air Circuit Breaker and Non-Fuse Circuit Breaker

Chapter 7 Optional AccessoriesC2000 Plus
7-9
7-2 Magnetic Contactor / Air Circuit Breaker and Non-fuse Circuit Breaker
Magnetic Contactor (MC) and Air Circuit Breaker (ACB)
It is recommended the surrounding temperature for MC should be ≥ 60°C and that for ACB should be ≥
50°C. In the meanwhile, consider temperature derating for components with ON/OFF switch in accordance
with the ambient temperature of the on-site distribution panel.
230V models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC/ACB
Selection (A)
A
VFD007C23A-21 5 6.4 11
VFD015C23A-21 8 12 22
VFD022C23A-21 11 16 32
VFD037C23A-21 17 20 32
B
VFD055C23A-21 25 28 55
VFD075C23A-21 33 36 65
VFD110C23A-21 49 52 85
C
VFD150C23A-21 65 72 130
VFD185C23A-21 75 83 150
VFD220C23A-21 90 99 150
D
VFD300C23A-00
VFD300C23A-21
120 124 185
VFD370C23A-00
VFD370C23A-21
146 143 225
E
VFD450C23A-00
VFD450C23A-21
180 171 265
VFD550C23A-00
VFD550C23A-21
215 206 330
VFD750C23A-00
VFD750C23A-21
255 245 400
F
VFD900C23A-00
VFD900C23A-21
346 331 500
460V models
Frame Model
Heavy Duty
Output Current (A)
Heavy Duty
Input Current (A)
MC/ACB
Selection (A)
A
VFD007C43A-21
3 4.3 7
VFD015C43A-21
4 5.9 9
VFD022C43A-21
6 8.7 18
VFD037C43A-21
9 14 22
VFD040C43A-21
10.5 15.5 32
VFD055C43A-21
12 17 32
B
VFD075C43A-21
18 20 32
VFD110C43A-21
24 26 40
VFD150C43A-21
32 35 55
Table 7-7
