Delta VFD110ED43S User Manual

Chapter 11 Summary of Parameter Settings | VFD-ED
11-7
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
Begin Time S3
 01-27
S-curve for Deceleration
Arrival Time S4
0.00–25.00 sec. 1.00 ○ ○ ○ ○ ○
01-28
Mode Selection when
Frequency < Fmin
0: Output waiting
1: Zero-speed operation
2: Fmin (fourth output
frequency setting)
1 ○ ○ ○
 01-29
Switch Frequency for
S3/S4 Changes to S5
0.00–299.00 Hz 0.00 ○ ○ ○ ○ ○
 01-30
S-curve for Deceleration
Arrival Time S5
0.00–25.00 sec. 1.00 ○ ○ ○ ○ ○
 01-31
Deceleration Time when
Operating without RUN
Command
0.00–600.00 sec. 2.00 ○ ○ ○ ○ ○
01-32
Direct docking mode only ◆
01-33
High Speed Time for Short
Floor
0.00–60.00 sec. 3.00 ○ ○ ○ ○ ○
01-34
Leveling Time for Short
Floor
0.00–60.00 sec. 3.00 ○ ○ ○ ○ ○
01-35
Limit for Direct Docking
Terminal
0.00–10.00 2.00 ○ ○ ○ ○ ○
01-36
Deceleration Distance for
Direct Docking Terminal
0.00–100.00 cm 30.00 ○ ○ ○ ○ ○
01-37
Deceleration Distance
Reference for Short Floor
0.00–655.35 m Read only ○ ○ ○ ○ ○
01-38
Short Floor/Direct Docking
Terminal Enabled
0000h: Disabled
0001h: Short floor enabled
0002h: Direct docking terminal
enabled
0003h: Short floor + direct
docking terminal enabled
0000h ○ ○ ○ ○ ○
01-39
Automatic Emergency
Deceleration Level
5.00–299.00 Hz 60.00 ○ ○ ○
 01-40
Deceleration Time for
Emergency Deceleration
0.00–600.00 sec. 2.00 ○ ○ ○
