Chapter 11 Summary of Parameter Settings | VFD-ED
11-8
02 Digital Input / Output Parameters
Pr. Parameter Name Setting Range Default
VF
VFPG
SVC
FOCPG
FOCPM
02-00
Two-wire/three-wire
Operation Control
0: FWD/STOP, REV/STOP
1: FWD/STOP, REV/STOP
(Line Start Lockout)
2: RUN/STOP, REV/FWD
3: RUN/STOP, REV/FWD
(Line Start Lockout)
4: Three-wire
5: Three-wire (Line Start Lockout)
0
02-01
Multi-Function Input
Command 1 (MI1)
0: no function
1
(The Stop terminal for
three-wire operation)
1: multi-step speed command 1
02-02
Multi-Function Input
Command 2 (MI2)
2: multi-step speed command 2 2
02-03
Multi-Function Input
Command 3 (MI3)
3: multi-step speed command 3 3
02-04
Multi-Function Input
Command 4 (MI4)
4: multi-step speed command 4 4
02-05
Multi-Function Input
Command 5 (MI5)
5: Reset 0
02-06
Multi-Function Input
Command 6 (MI6)
6: JOG command 0
02-07
Multi-Function Input
Command 7 (MI7)
7: Acceleration/ deceleration speed
inhibit
0
02-08
Multi-Function Input
Command 8 (MI8)
(Enable Drive terminal)
8: First, second
acceleration/deceleration time
40
9: Third, fourth
a
cceleration/deceleration
time
10: EF input (Pr.07-28)
11: Reserved
12: Stop output
1314: Reserved
15: AUI1 operation speed command
16: Reserved
17: AUI2 operation speed command
18: Emergency Stop (Pr.07-28)
1923: Reserved
24: FWD JOG command
25: REV JOG command
26: Reserved
27: ASR1/ASR2 selection
28: Emergency stop (EF1) (Motor
coasts to stop)
2930: Reserved
