Delta VFD150C43A-21 User Manual

Chapter 12 Descriptions of Parameter SettingsC2000 Plus
12.1-02-11
Settings Functions Descriptions
44
Negative limit switch
(NL)
Signal input for negative limit switch (NL).
ON: The drive executes homing based on Pr.11-68–Pr.11-74
settings.
45 Positive limit switch (PL)
Signal input for positive limit switch (PL).
ON: The drive executes homing based on Pr.11-68–Pr.11-74
settings.
46 Homing (ORG)
Origin point input.
ON: The drive executes homing based on Pr.11-68–Pr.11-74
settings.
47
Enable homing function
When this terminal is active in position control mode (Pr.00-
10=1), the drive executes homing based on Pr.11-68–Pr.11-74
settings.
48
Mechanical gear ratio
switch
ON: The mechanical gear ratio switches to the second set of
settings (refer to Pr.10-04–Pr.10-07).
OFF: Pr.10-04 and Pr.10-05 (the first set of settings)
ON: Pr.10-06 and Pr.10-07 (the second set of settings)
49 Enable drive
When the drive is enabled, the RUN command is valid.
When the drive is disabled, the RUN command is invalid.
When the drive is operating, the motor coasts to stop.
This function varies with MOx=45.
50
Slave dEb action to
execute
Enter the message setting in this parameter when the master
triggers dEb. This ensures that the slave also triggers dEb, then
the master and slave stop simultaneously.
51
Selection for PLC mode
(bit 0)
PLC status bit1 bit0
Disable PLC function (PLC 0) 0 0
Trigger PLC to operation (PLC 1) 0 1
Trigger PLC to stop (PLC 2) 1 0
No function 1 1
52
Selection for PLC mode
(bit 1)
53
Trigger CANopen quick
stop
When this function is enabled under CANopen control, it
changes to Quick Stop. Refer to Chapter 15 CANopen overview
for more details.
55
Brake release
When Pr.02-56 ≠ 0, connect the brake release signal to multi-
function input terminals. When the brake is opened, and the
drive does not receive its confirming signal, the Brk error occurs.
