Delta VFD150CP43B-21 User Manual

Chapter 7 Optional AccessoriesCP2000
7-54
Following table shows the sine-wave filter specification of Delta CP2000
200V–230V, 50 / 60 Hz
230V
Model
kW HP
Rated current (Arms)
Suggested sine-wave filter
part #
Output cable length
(Shielded or non-shielded)
Normal
Duty
Light
Duty
7 0.75 1 4.6 5 B84143V0006R227 1000
15 1.5 2 5 7.5 B84143V0011R227 1000
22 2.2 3 8 10 B84143V0011R227 1000
37 3.7 5 11 15 B84143V0025R227 1000
55 5.5 7.5 17 21 B84143V0025R227 1000
75 7.5 10 25 31 B84143V0033R227 1000
110 11 15 33 46 B84143V0050R227 1000
150 15 20 49 61 B84143V0066R227 1000
185 18.5 25 65 75 B84143V0075R227 1000
220 22 30 75 90 B84143V0095R227 1000
300 30 40 90 105 B84143V0132R227 1000
370 37 50 120 146 B84143V0180R227 1000
450 45 60 146 180 B84143V0180R227 1000
550 55 75 180 215 B84143V0250R227 1000
750 75 100 215 276 B84143V0320R227 1000
900 90 125 255 322 Non-available 1000
380V–460V, 50 / 60 Hz
460V
Model
kW HP
Rated current (Arms)
Suggested sine-wave filter
part #
Output cable length
(Shielded or non-shielded)
Normal
Duty
Light
Duty
007 0.75 1 2.8 3 B84143V0004R227 1000
015 1.5 2 3 4.2 B84143V0006R227 1000
022 2.2 3 4 5.5 B84143V0006R227 1000
037 3.7 5 6 8.5 B84143V0011R227 1000
040 4 5 9 10.5 B84143V0011R227 1000
055 5.5 7.5 10.5 13 B84143V0016R227 1000
075 7.5 10 12 18 B84143V0025R227 1000
110 11 15 18 24 B84143V0025R227 1000
150 15 20 24 32 B84143V0033R227 1000
185 18.5 25 32 38 B84143V0050R227 1000
220 22 30 38 45 B84143V0050R227 1000
300 30 40 45 60 B84143V0066R227 1000
370 37 50 60 73 B84143V0075R227 1000
450 45 60 73 91 B84143V0095R227 1000
550 55 75 91 110 B84143V0132R227 1000
750 75 100 110 150 B84143V0180R227 1000
900 90 125 150 180 B84143V0180R227 1000
1100 110 150 180 220 B84143V0250R227 1000
Table 7-63

Delta VFD150CP43B-21 Specifications
