Chapter 7 Optional AccessoriesCP2000
7-56
7-5 Zero Phase Reactors
Reactor
model (Note)
Recommended Wire Size
Wiring
Method
Qty
Corresponding motor drives
RF008X00A
or
T60006L2040W453
≤ 8 AWG ≤ 8.37 mm
2
Diagram A 1
VFD007CP23A-21; VFD007CP43A/4EA-21;
VFD015CP23A-21; VFD015CP43B/4EB-21;
VFD022CP23A-21;VFD022CP43B/4EB-21;
VFD037CP23A-21; VFD037CP43B/4EB-21;
VFD040CP43A/4EA-21; VFD055CP23A-21;
VFD055CP43B/4EB-21; VFD075CP43B/4EB-21;
VFD022CP53A-21; VFD037CP53A-21
RF004X00A
or
T60006L2050W565
≤ 4 AWG ≤ 21.15 mm
2
Diagram A 1
VFD075CP23A-21; VFD110CP23A-21; VFD110CP43B/4EB
-21; VFD150CP23A-21; VFD150CP43B/4EB-21;
VFD185CP43B/4EB-21; VFD055CP53A-21;
VFD075CP53A-21; VFD110CP53A-21; VFD150CP53A-21
RF002X00A
or
T60006L2160V066
≤ 2 AWG ≤ 33.62 mm
2
Diagram A 1
VFD185CP23A-21; VFD220CP23A-21;
VFD220CP43A/4EA-21; VFD300CP23A-21;
VFD300CP43B/4EB-21; VFD370CP43B/4EB-21;
VFD185CP63A-21; VFD220CP63A-21; VFD300CP63A-21;
VFD370CP63A-21; VFD370CP23A-00/23A-21;
VFD450CP23A-00/23A-21; VFD750CP43B-00/43B-21;
VFD900CP43A-00/43A-21; VFD450CP63A-00;
VFD550CP63A-00; VFD450CP63A-21; VFD550CP63A-21
RF300X00A
or
T60006L2160V066
≤ 300 MCM ≤ 152 mm
2
Diagram A 1
VFD450CP43S-00; VFD550CP43S-00; VFD450CP43S-21;
VFD550CP43S-21;
VFD550CP23A-00/23A-21; VFD750CP23A-00/23A-21;
VFD900CP23A-00/23A-21; VFD1100CP43A-00/43A-21;
VFD1320CP43B-00/43B-21; VFD750CP63A-00;
VFD900CP63A-00; VFD1100CP63A-00;
VFD1320CP63A-00; VFD750CP63A-21; VFD900CP63A-21;
VFD1100CP63A-21; VFD1320CP63A-21;
VFD1600CP43A-00/43A-21; VFD1850CP43B-00/43B-21;
VFD1600CP63A-00; VFD2000CP63A-00;
VFD1600CP63A-21; VFD2000CP63A-21;
VFD2200CP43A-00/43A-21; VFD2800CP43A-00/43A-21;
VFD2500CP63A-00; VFD3150CP63A-00;
VFD2500CP63A-21; VFD3150CP63A-21;
VFD3150CP43A-00/43C-00/43C-21;
VFD3550CP43A-00/43C-00/43C-21;
VFD4000CP43A-00/43C-00/43C-21; VFD4000CP63A-00;
VFD4500CP63A-00; VFD5600CP63A-00;
VFD6300CP63A-00; VFD4000CP63A-21;
VFD4500CP63A-21; VFD5600CP63A-21;
VFD6300CP63A-21
*575V insulated power cable
Table 7-66
To Next Page
