Delta VFD150CP43B-21 User Manual

Chapter 11 Summary of Parameter SettingsCP2000
11-13
Pr. Parameter Name Setting Range Default
55: Brake release
56: Local / Remote selection
58: Enable fire mode (with RUN command)
59: Enable fire mode (without RUN command)
60: Disable all the motors
61: Disable Motor 1
62: Disable Motor 2
63: Disable Motor 3
64: Disable Motor 4
65: Disable Motor 5
66: Disable Motor 6
67: Disable Motor 7
68: Disable Motor 8
69: Preheating command
 02-09 UP / DOWN key mode
0: UP / DOWN by acceleration / deceleration time
1: UP / DOWN constant speed (Pr.02-10)
0
 02-10
Constant speed, acceleration /
deceleration speed of the UP /
DOWN key
0.001–1.000 Hz / ms 0.001
 02-11 Multi-function input response time 0.000–30.000 sec. 0.005
 02-12 Multi-function input mode selection 0000h–FFFFh (0: N.O.; 1: N.C.） 0000h
 02-13 Multi-function output 1 RLY1 0: No function 11
 02-14 Multi-function output 2 RLY2 1: Indication during RUN 1
 02-15 Multi-function output 3 RLY3 2: Operation speed reached 66
 02-36
Output terminal of the I/O extension
card (MO10)
or (RA10)
3: Desired frequency reached 1 (Pr.02-22)
4: Desired frequency reached 2 (Pr.02-24)
0
 02-37
Output terminal of I/O extension card
(MO11)
or (RA11)
5: Zero speed (Frequency command)
6: Zero speed including STOP (Frequency
0
 02-38
Output terminal of I/O extension card
(RA12)
command)
7: Over-torque 1 (Pr.06-06–06-08)
0
 02-39
Output terminal of I/O extension card
(RA13)
8: Over-torque 2 (Pr.06-09–06-11)
9: Drive is ready
0
 02-40
Output terminal of I/O extension card
(RA14)
10: Low voltage warning (Lv) (Pr.06-00)
11: Malfunction indication
0
 02-41
Output terminal of I/O extension card
(RA15)
12: Mechanical brake release (Pr.02-32)
13: Over-heat warning (Pr.06-15)
0
 02-42
Output terminal of I/O extension card
(MO16 virtual terminal)
14: Software brake signal indication (Pr.07-00)
15: PID feedback error (Pr.08-13, Pr.08-14)
0
 02-43
Output terminal of I/O extension card
(MO17 virtual terminal)
16: Slip error (oSL)
17: Count value reached, does not return to 0
0
 02-44
Output terminal of I/O extension card
(MO18 virtual terminal)
(Pr.02-20)
18: Count value reached, returns to 0
0
 02-45
Output terminal of I/O extension card
(MO19 virtual terminal)
(Pr.02-19)
19: External interrupt B.B. input (Base Block)
0
 02-46
Output terminal of I/O extension card
(MO20 virtual terminal)
20: Warning output
21: Over-voltage
0
22: Over-current stall prevention
23: Over-voltage stall prevention
