Chapter 12 Description of Parameter SettingsCP2000
12.1-07-4
kW 185 220 300 370 450 550 750 900
HP 25 30 40 50 60 75 100 125
Delay time (sec.) 1.1 1.2 1.3 1.4 1.5 1.6 1.7 1.8
Current Limit for Speed Search
Default: 100
Settings 20–200% (100% corresponds to the light-load rated current of the drive)
The AC motor drive executes speed tracking only if the output current is greater than the value
set in Pr.07-09.
