Page #689 background image
Chapter 16 PLC Function ApplicationsCP2000
16-6
PLC mode
PLC Mode select bit1(52) PLC Mode select bit0 (51)
Using KPC-CC01
Disable OFF OFF
PLC Run OFF ON
PLC Stop ON OFF
Maintain previous
state
ON ON
NOTE
When input/output terminals (FWD REV MI1–MI8, MI10–15, Relay1–3, RY10–RY15,
MO10–MO11,) are included in the PLC program, these input/output terminals will only be
used by the PLC. As an example, when the PLC program controls Y0 during PLC operation
(PLC1 or PLC2), the corresponding output terminal relay (RA/RB/RC) will operate in
accordance with the program. At this time, the multifunctional input/output terminal setting
will be ineffective. Because these terminal functions are already being used by the PLC, the
DI DO AO in use by the PLC can be determined by looking at Pr.02-52, Pr.02-53, and
Pr.03-30.
When the PLC's procedures use special register D1040, the corresponding AO contact
AFM1 will be occupied, and AFM2 corresponding to special register D1045 will have the
same situation.
Pr.03-30 monitors the state of action of the PLC function analog output terminal; bit0
corresponds to the AFM1 action state, and bit1 corresponds to the AFM2 action state.
