Chapter 3 UnpackingCP2000
3-28
Ensure the lifting hook properly goes through the
lifting hole, as shown in the following diagram.
Applicable to Frame D0–E
Applicable to Frame F–H
Ensure the angle between the lifting holes and the
lifting device is within the specification, as shown
in the following figure.
Applicable to Frame D0–E
Applicable to Frame F–H, 690V Frame H3
Following drawing is only for demonstration, it may
be slightly different with the machine you have.
Figure 3-85
Figure 3-86
Figure 3-87
Figure 3-88
