Chapter 15 CANopen OverviewMS300

642

NOTE:

1. Read 6043 to get the current rotation speed (unit: rpm)

2. Read bit 10 of 6041 to check if the rotation speed has reached the targeting value (0: Not

reached; 1: Reached).
