Chapter 16 PLC Function ApplicationsMS300
725
Convert angle to diameter
Continuous
execution type
Notes on operand usage:
Refer to the function specifications table for each device in series
for the scope of device usage.
S: data source (angle). D: result of conversion (diameter).
Uses the following formula to convert angles to radians.
Diameter = Angle × (π/180)
When X0 = ON, converts the angle of the designated binary floating point
number (D1, D0) to radians and stores the result in (D11, D10); the result is a
binary floating point number.
