Chapter 9 SpecificationsMS300
179
9-2 230V Models
230V models one-phase
Frame
A
B
Model VFD_ _ _ _ _ _ _ _AA
1A6MS21_ _ _
2A8MS21_ _ _
1A6MS21AFS
2A8MS21AFS
4A8MS21_ _ _
ANS
ENS
ANS
ENS
ANS
ENS
Applicable Motor Output (kW)
0.2
0.4
0.2
0.4
0.75
Applicable Motor Output (HP)
1/4
1/2
1/4
1/2
1
Outp
ut*
Heavy
Duty
Rated Output Capacity (kVA)
0.6
1.1
0.6
1.1
1.8
Rated Output Current (A)
1.6
2.8
1.6
2.8
4.8
Carrier Frequency (kHz)
2–15 (Default: 4)
Normal
Duty
Rated Output Capacity (kVA)
0.7
1.2
0.7
1.2
1.9
Rated Output Current (A)
1.8
3.2
1.8
3.2
5
Carrier Frequency (kHz)
2–15 (Default: 4)
Input
Rated Input
Current (A)
Heavy Duty
5.1
7.3
5.1
7.3
10.8
Normal Duty
5.8
8.3
5.8
8.3
11.3
Rated Voltage / Frequency
One-phase 200–240 V
AC
(-15–10%), 50／60 Hz
Mains Input Voltage Range (V
AC
)
170–265
Mains Frequency Range (Hz)
47–63
Weight (kg)
0.65
0.76
1.32
1.32
0.95
Cooling Method
Convective cooling
Fan cooling
Convective
cooling
EMC Filter
Optional
Built-in
Optional
IP Rating
IP20
IP40*
IP20
IP40*
IP20
IP40*
Table 9-2
NOTE:
1. Output*: Default is heavy duty.
2. IP40*: The IP ratings of the wiring area (main circuit terminals and control terminals for frame A/B/C/D/E/F)
and the vent near the capacitor (frame C/D/E/F) are both IP20.
3. The value of the carrier frequency is a factory default. Decrease the current value if you need to increase the
carrier frequency. Refer to Section 9-7 Derating for Ambient Temperature and Altitude for details.
4. For shock or impact load applications, select a drive with a larger capacity model.
