Delta VFD1A5MS43ANSAA User Manual

Chapter 11 Summary of Parameter SettingsMS300
215
Pr.
Explanation
Settings
Default
01-36
Rated / Base Voltage of
Motor 2
115V / 230V models: 0.0–255.0 V
460V models: 0.0–510.0 V
575V models: 0.0–637.0 V
220.0
440.0
575.0
01-37
Mid-Point Frequency 1 of
Motor 2
0.00–599.00 Hz
3.00

01-38
Mid-Point Voltage 1 of
Motor 2
115V / 230V models: 0.0–240.0 V
460V models: 0.0–480.0 V
575V models: 0.0–600.0 V
11.0
22.0
40.0
01-39
Mid-Point Frequency 2 of
Motor 2
0.00–599.00 Hz
1.50

01-40
Mid-Point Voltage 2 of
Motor 2
115V / 230V models: 0.0–240.0 V
460V models:0.0–480.0 V
575V models: 0.0–600.0 V
5.0
10.0
26.1
01-41
Minimum Output Frequency
of Motor 2
0.00–599.00 Hz
0.50

01-42
Minimum Output Voltage of
Motor 2
115V / 230V models: 0.0–240.0 V
460V models: 0.0–480.0 V
575V models: 0.0–600.0 V
1.0
2.0
16.7
01-43
V/F Curve Selection
0: V/F curve determined by Pr.01-00–Pr.01-08
1: V/F curve to the power of 1.5
2: V/F curve to the power of 2
0

01-44
Auto-Acceleration and
Auto-Deceleration Setting
0: Linear acceleration and deceleration
1: Auto-acceleration and linear deceleration
2: Linear acceleration and auto-deceleration
3: Auto-acceleration and auto-deceleration
4: Stall prevention by auto-acceleration and
auto-deceleration (limited by Pr.01-12–Pr.01-21)
0
01-45
Time Unit for Acceleration /
Deceleration and S-Curve
0: Unit 0.01 sec.
1: Unit 0.1 sec.
0

01-46
CANopen Quick Stop Time
Pr.01-45 = 0: 0.00–600.00 sec.
Pr.01-45 = 1: 0.0–6000.0 sec.
1.00
1.0
01-49
Regenerative Energy
Restriction Control Method
0: Disable
1: Over voltage energy restriction
2: Traction energy control (TEC)
0
01-52
Maximum Operation
Frequency of Motor 2
0.00–599.00 Hz
60.00 /
50.00
01-53
Maximum Operation
Frequency of Motor 3
0.00–599.00 Hz
60.00 /
50.00
