Chapter 13 Warning CodesMS300
482
ID No.
Display on LCD Keypad
Warning Name
Description
11
PID feedback error
(PID)
PID feedback loss (warning for analog feedback signal;
works only when PID enables)
Action and Reset
Action Condition
When the analog input is lower than 4 mA (only detects analog input 4–20 mA)
Action Time
Pr.08-08
Warning Setting Parameter
Pr.08-09
0: Warn and continue operation
1: Fault and ramp to stop
2: Fault and coast to stop
3: Warn and operate at last frequency
Reset Method
Auto
“Warningoccurs when Pr.08-09 = 0 or 3. The “Warningautomatically
clears when the feedback signal is larger than 4 mA.
Manual
“Erroroccurs when Pr.08-09 = 1 or 2. You must reset manually.
Reset Condition
Immediately reset
Record
Records when Pr.08-09 = 1 or 2 (“Error”).
Does not record when Pr.08-09 = 3 (“Warning”).
Cause
Corrective Actions
Loose or broken PID feedback
wiring
Tighten the terminals again.
Replace with a new cable.
Feedback device malfunction
Replace with a new feedback device.
Hardware error
If the PID error still occurs after checking all the wiring, return to the factory for
repair.
