Chapter 7 Optional AccessoriesMS300
49
460V three-phase
Model
Applicable
Motor
125% Braking Torque / 10% ED*
1
Max. Braking Torque
HP
kW
Braking
Torque*
2
(kg-m)
Resistor Value
Spec. for Each
AC Motor Drive
Brake Resistor for
each Brake Unit
Braking
Current
(A)
Min.
Resistor
Value (Ω)
Max. Total
Braking
Current (A)
Peak
Power
(kW)
Part No.*
3
Q’ty
Usage
VFD1A5MS43XNSAA
VFD1A5MS43AFSAA
0.5
0.4
0.3
80 W 750 Ω
BR080W750
1
1
380.0
2
1.5
VFD2A7MS43XNSAA
VFD2A7MS43AFSAA
1
0.75
0.5
80 W 750 Ω
BR080W750
1
1
190.0
4
3.0
VFD4A2MS43XNSAA
VFD4A2MS43AFSAA
2
1.5
1
200 W 360 Ω
BR200W360
1
2.1
126.7
6
4.6
VFD5A5MS43XNSAA
VFD5A5MS43AFSAA
3
2.2
1.5
300 W 250 Ω
BR300W250
1
3
108.6
7
5.3
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
4
3
2
400W 150Ω
BR400W150
1
2 in
series
5.1
95.0
8
6.1
VFD9A0MS43XNSAA
VFD9A0MS43AFSAA
5
3.7/4
2.5
400 W 150 Ω
BR400W150
1
5.1
84.4
9
6.8
VFD13AMS43XNSAA
VFD13AMS43AFSAA
7.5
5.5
3.7
1000 W 75 Ω
BR1K0W075
1
10.2
50.7
15
11.4
VFD17AMS43XNSAA
VFD17AMS43AFSAA
10
7.5
5.1
1000 W 75 Ω
BR1K0W075
1
10.2
40.0
19
14.4
VFD25AMS43XNSAA
VFD25AMS43AFSAA
15
11
7.4
1500 W 43 Ω
BR1K5W043
1
17.6
33.0
23
17.5
VFD32AMS43XNSAA
VFD32AMS43AFSAA
20
15
10.2
2000 W 32 Ω
BR1K0W016
2
2 in
series
24
26.2
29
22.0
VFD38AMS43XNSAA
VFD38AMS43AFSAA
25
18
12.2
2000 W 32 Ω
BR1K0W016
2
2 in
series
24
26.2
29
22.0
VFD45AMS43XNSAA
VFD45AMS43AFSAA
30
22
14.9
3000 W 26 Ω
BR1K5W013
2
2 in
series
29
23.0
33
25.1
Table 7-4
575V three-phase
Model
Applicable
Motor
125% Braking Torque / 10% ED*
1
Max. Braking Torque
HP
kW
Braking
Torque*
2
(kg-m)
Resistor Value
Spec. for Each
AC Motor Drive
Brake Resistor for
each Brake Unit
Braking
Current
(A)
Min.
Resistor
Value (Ω)
Max. Total
Braking
Current (A)
Peak
Power
(kW)
Part No.*
3
Q’ty
Usage
VFD1A7MS53ANSAA
1
0.75
0.5
80W 750Ω
BR080W750
1
-
1.2
280.0
4
4.5
VFD3A0MS53ANSAA
2
1.5
1
200W 360Ω
BR200W360
1
-
2.6
186.7
6
6.7
VFD4A2MS53ANSAA
3
2.2
1.5
300W 400Ω
BR300W400
1
-
2.3
160.0
7
7.8
VFD6A6MS53ANSAA
5
3.7
2.5
500W 100Ω
BR500W100
1
-
9.2
93.3
12
13.4
VFD9A9MS53ANSAA
7.5
5.5
3.7
750W 140Ω
BR750W140
1
-
6.6
80.0
14
15.7
VFD12AMS53ANSAA
10
7.5
5.1
1000W 75Ω
BR1K0W075
1
-
12.3
70.0
16
17.9
Table 7-5
NOTE:
*1
Calculation for 125% brake torque: (kW) × 125% × 0.8; where 0.8 is motor efficiency.
Because of the limited resistor power, the longest operation time for 10% ED is 10 seconds (ON: 10 sec. / OFF: 90 sec.).
*2
The calculation of the brake resistor is based on a four-pole motor (1800 rpm).
*3
For heat dissipation, a resistors of 400 W or lower should be fixed to the frame and maintain the surface temperature below
250°C; a resistor of 1000 W and above should maintain the surface temperature below 350°C.
(If the surface temperature is higher than the temperature limit, install extra cooling or increase the size of the resistor.)
