Chapter 7 Optional AccessoriesMS300
54
Non-fuse Circuit Breaker
Comply with the UL standard: Per UL 508, paragraph 45.8.4, part a.
The rated current of the non-fuse circuit breaker should be 1.6–2.6 times the drive’s rated input current.
The recommended current values are shown in the table below. Compare the time characteristics of the
non-fuse circuit breaker with those of the drive’s overheated protection to ensure that there is no tripping.
Model
Voltage / One-phase (Three-
phase)
Breaker Rated Input
Recommended Current (A)
VFD1A6MS11ANSAA
VFD1A6MS11ENSAA
115V / One-phase
20
VFD2A5MS11ANSAA
VFD2A5MS11ENSAA
25
VFD4A8MS11ANSAA
VFD4A8MS11ENSAA
50
VFD1A6MS21ANSAA
VFD1A6MS21ENSAA
VFD1A6MS21AFSAA
230V / One-phase
15
VFD2A8MS21ANSAA
VFD2A8MS21ENSAA
VFD2A8MS21AFSAA
20
VFD4A8MS21ANSAA
VFD4A8MS21ENSAA
VFD4A8MS21AFSAA
30
VFD7A5MS21ANSAA
VFD7A5MS21ENSAA
VFD7A5MS21AFSAA
45
VFD11AMS21ANSAA
VFD11AMS21ENSAA
VFD11AMS21AFSAA
70
VFD1A6MS23ANSAA
VFD1A6MS23ENSAA
230V / Three-phase
15
VFD2A8MS23ANSAA
VFD2A8MS23ENSAA
15
VFD4A8MS23ANSAA
VFD4A8MS23ENSAA
15
VFD7A5MS23ANSAA
VFD7A5MS23ENSAA
25
VFD11AMS23ANSAA
VFD11AMS23ENSAA
40
VFD17AMS23ANSAA
VFD17AMS23ENSAA
60
VFD25AMS23ANSAA
VFD25AMS23ENSAA
63
VFD33AMS23ANSAA
VFD33AMS23ENSAA
90
VFD49AMS23ANSAA
VFD49AMS23ENSAA
125
VFD65AMS23ANSAA
VFD65AMS23ENSAA
160
