Chapter 7 Optional AccessoriesMS300
81
460V Three-phase
Drive Model
Normal Duty
Rated Current
(Arms)
Without an AC Output Reactor
With an AC Output Reactor
Shielded Cable
(meter)
Non-shielded
Cable (meter)
Shielded
Cable
(meter)
Non-shielded
Cable
(meter)
VFD5A5MS43ANSAA
VFD5A5MS43ENSAA
VFD5A5MS43AFSAA
6.5
50
75
75
115
VFD7A3MS43ANSAA
VFD7A3MS43ENSAA
VFD7A3MS43AFSAA
8.9
75
150
150
225
VFD9A0MS43ANSAA
VFD9A0MS43ENSAA
VFD9A0MS43AFSAA
10.5
50
75
75
15
VFD13AMS43ANSAA
VFD13AMS43ENSAA
VFD13AMS43AFSAA
15.7
VFD17AMS43ANSAA
VFD17AMS43ENSAA
VFD17AMS43AFSAA
20.5
100
150
150
225
VFD25AMS43ANSAA
VFD25AMS43ENSAA
VFD25AMS43AFSAA
28
VFD32AMS43ANSAA
VFD32AMS43ENSAA
VFD32AMS43AFSAA
36
VFD38AMS43ANSAA
VFD38AMS43ENSAA
VFD38AMS43AFSAA
41.5
VFD45AMS43ANSAA
VFD45AMS43ENSAA
VFD45AMS43AFSAA
49
Table 7-40
575V Three-phase
Drive Model
Normal Duty
Rated Current
(Arms)
Without an AC Output Reactor*
1
With an AC Output Reactor
Shielded Cable
(meter)
Non-shielded
Cable (meter)
Shielded
Cable
(meter)
Non-shielded
Cable
(meter)
VFD1A7MS53ANSAA
2.1
15
55
N/A
N/A
VFD3A0MS53ANSAA
3.6
50
80
VFD4A2MS53ANSAA
5
65
120
VFD6A6MS53ANSAA
8.5
65
295
VFD9A9MS53ANSAA
11.5
145
320
VFD12AMS53ANSAA
15
145
320
Table 7-41
*
1
Without an AC output reactor: Use the motor cable length of the 575V drive model only for 4 kHz carrier
frequency (Pr.00-17 = 4). If you use it for > 4 kHz carrier frequency, you may need to reduce the motor cable
length to prevent over-current protection caused by large leakage current, depending on the actual on-site
situations.
